De Novo Design of Polynuclear Transition Metal Clusters in Helix Bundles-4DH1

Experimental Data Snapshot

  • Resolution: 1.90 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.219
  • R-Value Observed: 0.220

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


De Novo Design of Tetranuclear Transition Metal Clusters Stabilized by Hydrogen-Bonded Networks in Helical Bundles.

Zhang, S.Q.Chino, M.Liu, L.Tang, Y.Hu, X.DeGrado, W.F.Lombardi, A.

(2018) J Am Chem Soc 140: 1294-1304

  • DOI: https://doi.org/10.1021/jacs.7b08261
  • Primary Citation of Related Structures:
    5WLJ, 5WLK, 5WLL, 5WLM

  • PubMed Abstract:

    De novo design provides an attractive approach to test the mechanism by which metalloproteins define the geometry and reactivity of their metal ion cofactors. While there has been considerable progress in designing proteins that bind transition metal ions including iron-sulfur clusters, the design of tetranuclear clusters with oxygen-rich environments has not been accomplished. Here, we describe the design of tetranuclear clusters, consisting of four Zn 2+ and four carboxylate oxygens situated at the vertices of a distorted cube-like structure. The tetra-Zn 2+ clusters are bound at a buried site within a four-helix bundle, with each helix donating a single carboxylate (Glu or Asp) and imidazole (His) ligand, as well as second- and third-shell ligands. Overall, the designed site consists of four Zn 2+ and 16 polar side chains in a fully connected hydrogen-bonded network. The designed proteins have apolar cores at the top and bottom of the bundle, which drive the assembly of the liganding residues near the center of the bundle. The steric bulk of the apolar residues surrounding the binding site was varied to determine how subtle changes in helix-helix packing affect the binding site. The crystal structures of two of four proteins synthesized were in good agreement with the overall design; both formed a distorted cuboidal site stabilized by flanking second- and third-shell interactions that stabilize the primary ligands. A third structure bound a single Zn 2+ in an unanticipated geometry, and the fourth bound multiple Zn 2+ at multiple sites at partial occupancy. The metal-binding and conformational properties of the helical bundles in solution, probed by circular dichroism spectroscopy, analytical ultracentrifugation, and NMR, were consistent with the crystal structures.

  • Organizational Affiliation

    Department of Chemistry, University of Pennsylvania , 209 South 33rd Street, Philadelphia, Pennsylvania 19104-6396, United States.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Helical Bundle 4DH1
A, B, C, D
28synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.90 Å
  • R-Value Free: 0.238
  • R-Value Work: 0.219
  • R-Value Observed: 0.220
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.782α = 90
b = 80.782β = 90
c = 64.923γ = 120
Software Package:
Software NamePurpose
HKL-2000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM54616

Revision History  (Full details and data files)

  • Version 1.0: 2018-01-03
    Type: Initial release
  • Version 1.1: 2018-01-31
    Changes: Database references
  • Version 1.2: 2018-02-07
    Changes: Database references
  • Version 1.3: 2020-01-01
    Changes: Author supporting evidence
