5VOX | pdb_00005vox

Yeast V-ATPase in complex with Legionella pneumophila effector SidK (rotational state 1)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 6.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 5VOX

This is version 1.3 of the entry. See complete history

Literature

Molecular basis for the binding and modulation of V-ATPase by a bacterial effector protein.

Zhao, J.Beyrakhova, K.Liu, Y.Alvarez, C.P.Bueler, S.A.Xu, L.Xu, C.Boniecki, M.T.Kanelis, V.Luo, Z.Q.Cygler, M.Rubinstein, J.L.

(2017) PLoS Pathog 13: e1006394-e1006394

  • DOI: https://doi.org/10.1371/journal.ppat.1006394
  • Primary Citation Related Structures:
    5UF5, 5UFK, 5VOX, 5VOY, 5VOZ

  • PubMed Abstract:

    Intracellular pathogenic bacteria evade the immune response by replicating within host cells. Legionella pneumophila, the causative agent of Legionnaires' Disease, makes use of numerous effector proteins to construct a niche supportive of its replication within phagocytic cells. The L. pneumophila effector SidK was identified in a screen for proteins that reduce the activity of the proton pumping vacuolar-type ATPases (V-ATPases) when expressed in the yeast Saccharomyces cerevisae. SidK is secreted by L. pneumophila in the early stages of infection and by binding to and inhibiting the V-ATPase, SidK reduces phagosomal acidification and promotes survival of the bacterium inside macrophages. We determined crystal structures of the N-terminal region of SidK at 2.3 Å resolution and used single particle electron cryomicroscopy (cryo-EM) to determine structures of V-ATPase:SidK complexes at ~6.8 Å resolution. SidK is a flexible and elongated protein composed of an α-helical region that interacts with subunit A of the V-ATPase and a second region of unknown function that is flexibly-tethered to the first. SidK binds V-ATPase strongly by interacting via two α-helical bundles at its N terminus with subunit A. In vitro activity assays show that SidK does not inhibit the V-ATPase completely, but reduces its activity by ~40%, consistent with the partial V-ATPase deficiency phenotype its expression causes in yeast. The cryo-EM analysis shows that SidK reduces the flexibility of the A-subunit that is in the 'open' conformation. Fluorescence experiments indicate that SidK binding decreases the affinity of V-ATPase for a fluorescent analogue of ATP. Together, these results reveal the structural basis for the fine-tuning of V-ATPase activity by SidK.


  • Organizational Affiliation
    • The Hospital for Sick Children Research Institute, Toronto, Ontario, Canada.

Macromolecule Content

  • Total Structure Weight: 1,151.45 kDa
  • Atom Count: 34,724
  • Modeled Residue Count: 8,691
  • Deposited Residue Count: 10,375
  • Unique protein chains: 16

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase catalytic subunit A,V-type proton ATPase catalytic subunit A
A, C, E
617Saccharomyces cerevisiae S288CMutation(s): 0
EC: 3.6.3.14 (PDB Primary Data), 3.1 (PDB Primary Data), 7.1.2.2 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for P17255 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P17255
Go to UniProtKB:  P17255
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP17255
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit B
B, D, F
517Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P16140 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P16140
Go to UniProtKB:  P16140
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP16140
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit E
G, I, K
233Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P22203 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P22203
Go to UniProtKB:  P22203
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22203
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit G
H, J, L
114Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P48836 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P48836
Go to UniProtKB:  P48836
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48836
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit D256Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P32610 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32610
Go to UniProtKB:  P32610
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32610
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit F118Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P39111 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P39111
Go to UniProtKB:  P39111
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP39111
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit C392Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P31412 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P31412
Go to UniProtKB:  P31412
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP31412
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit H478Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P41807 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P41807
Go to UniProtKB:  P41807
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP41807
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit d345Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P32366 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32366
Go to UniProtKB:  P32366
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32366
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit c''213Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P23968 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P23968
Go to UniProtKB:  P23968
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23968
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 11
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit c'164Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P32842 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32842
Go to UniProtKB:  P32842
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32842
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 12
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit c
AA [auth a],
T,
U,
V,
W,
X,
Y,
Z
160Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P25515 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P25515
Go to UniProtKB:  P25515
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25515
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 13
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit a, vacuolar isoformBA [auth b]840Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P32563 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32563
Go to UniProtKB:  P32563
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32563
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 14
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit eCA [auth c]73Saccharomyces cerevisiae S288CMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q3E7B6 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q3E7B6
Go to UniProtKB:  Q3E7B6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ3E7B6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 15
MoleculeChains  Sequence LengthOrganismDetailsImage
V-type proton ATPase subunit fDA [auth d]54Saccharomyces cerevisiae S288CMutation(s): 0
Find similar proteins by:|  3D Structure
Entity ID: 16
MoleculeChains  Sequence LengthOrganismDetailsImage
effector protein SidKEA [auth e],
FA [auth f],
GA [auth g]
573Legionella pneumophila subsp. pneumophila ATCC 43290Mutation(s): 0
Gene Names: lp12_0990

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 6.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data

  • Released Date: 2017-06-21
  • Deposition Author(s): Zhao, J.

Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)CanadaMOP 81294
Canadian Institutes of Health Research (CIHR)CanadaMOP-48370
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR56AI103168
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR21AI10571
Natural Sciences and Engineering Research Council (NSERC, Canada)CanadaRGPIN-2015-05372

Revision History  (Full details and data files)

  • Version 1.0: 2017-06-21
    Type: Initial release
  • Version 1.1: 2017-09-20
    Changes: Author supporting evidence, Data collection
  • Version 1.2: 2019-12-11
    Changes: Author supporting evidence
  • Version 1.3: 2024-03-13
    Changes: Data collection, Database references
