5UFK

Structure of the effector protein SidK (lpg0968) from Legionella pneumophila


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.212
  • R-Value Work: 0.172

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Molecular basis for the binding and modulation of V-ATPase by a bacterial effector protein.

Zhao, J.Beyrakhova, K.Liu, Y.Alvarez, C.P.Bueler, S.A.Xu, L.Xu, C.Boniecki, M.T.Kanelis, V.Luo, Z.Q.Cygler, M.Rubinstein, J.L.

(2017) PLoS Pathog. 13: e1006394-e1006394

  • DOI: 10.1371/journal.ppat.1006394
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Intracellular pathogenic bacteria evade the immune response by replicating within host cells. Legionella pneumophila, the causative agent of Legionnaires' Disease, makes use of numerous effector proteins to construct a niche supportive of its replica ...

    Intracellular pathogenic bacteria evade the immune response by replicating within host cells. Legionella pneumophila, the causative agent of Legionnaires' Disease, makes use of numerous effector proteins to construct a niche supportive of its replication within phagocytic cells. The L. pneumophila effector SidK was identified in a screen for proteins that reduce the activity of the proton pumping vacuolar-type ATPases (V-ATPases) when expressed in the yeast Saccharomyces cerevisae. SidK is secreted by L. pneumophila in the early stages of infection and by binding to and inhibiting the V-ATPase, SidK reduces phagosomal acidification and promotes survival of the bacterium inside macrophages. We determined crystal structures of the N-terminal region of SidK at 2.3 Å resolution and used single particle electron cryomicroscopy (cryo-EM) to determine structures of V-ATPase:SidK complexes at ~6.8 Å resolution. SidK is a flexible and elongated protein composed of an α-helical region that interacts with subunit A of the V-ATPase and a second region of unknown function that is flexibly-tethered to the first. SidK binds V-ATPase strongly by interacting via two α-helical bundles at its N terminus with subunit A. In vitro activity assays show that SidK does not inhibit the V-ATPase completely, but reduces its activity by ~40%, consistent with the partial V-ATPase deficiency phenotype its expression causes in yeast. The cryo-EM analysis shows that SidK reduces the flexibility of the A-subunit that is in the 'open' conformation. Fluorescence experiments indicate that SidK binding decreases the affinity of V-ATPase for a fluorescent analogue of ATP. Together, these results reveal the structural basis for the fine-tuning of V-ATPase activity by SidK.


    Organizational Affiliation

    The Hospital for Sick Children Research Institute, Toronto, Ontario, Canada.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
effector protein SidK
A
266Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)Mutation(s): 0
Find proteins for Q5ZWW6 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513))
Go to UniProtKB:  Q5ZWW6
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MLY
Query on MLY
A
L-PEPTIDE LINKINGC8 H18 N2 O2LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.3 Å
  • R-Value Free: 0.212
  • R-Value Work: 0.172
  • Space Group: P 43
Unit Cell:
Length (Å)Angle (°)
a = 52.960α = 90.00
b = 52.960β = 90.00
c = 127.440γ = 90.00
Software Package:
Software NamePurpose
PHENIXphasing
PHENIXrefinement
XDSdata scaling
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health ResearchCanadaMOP-48370

Revision History

  • Version 1.0: 2017-05-10
    Type: Initial release
  • Version 1.1: 2017-06-21
    Type: Database references
  • Version 1.2: 2017-09-20
    Type: Author supporting evidence
