Structural insight into an intramembrane enzyme for archaeal membrane lipids biosynthesis

Experimental Data Snapshot

  • Resolution: 2.40 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.207
  • R-Value Observed: 0.211

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Structural and mechanistic insights into the biosynthesis of CDP-archaeol in membranes.

Ren, S.Caforio, A.Yang, Q.Sun, B.Yu, F.Zhu, X.Wang, J.Dou, C.Fu, Q.Huang, N.Sun, Q.Nie, C.Qi, S.Gong, X.He, J.Wei, Y.Driessen, A.J.Cheng, W.

(2017) Cell Res 27: 1378-1391

  • DOI: https://doi.org/10.1038/cr.2017.122
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The divergence of archaea, bacteria and eukaryotes was a fundamental step in evolution. One marker of this event is a major difference in membrane lipid chemistry between these kingdoms. Whereas the membranes of bacteria and eukaryotes primarily consist of straight fatty acids ester-bonded to glycerol-3-phosphate, archaeal phospholipids consist of isoprenoid chains ether-bonded to glycerol-1-phosphate. Notably, the mechanisms underlying the biosynthesis of these lipids remain elusive. Here, we report the structure of the CDP-archaeol synthase (CarS) of Aeropyrum pernix (ApCarS) in the CTP- and Mg 2+ -bound state at a resolution of 2.4 Å. The enzyme comprises a transmembrane domain with five helices and cytoplasmic loops that together form a large charged cavity providing a binding site for CTP. Identification of the binding location of CTP and Mg 2+ enabled modeling of the specific lipophilic substrate-binding site, which was supported by site-directed mutagenesis, substrate-binding affinity analyses, and enzyme assays. We propose that archaeol binds within two hydrophobic membrane-embedded grooves formed by the flexible transmembrane helix 5 (TM5), together with TM1 and TM4. Collectively, structural comparisons and analyses, combined with functional studies, not only elucidated the mechanism governing the biosynthesis of phospholipids with ether-bonded isoprenoid chains by CTP transferase, but also provided insights into the evolution of this enzyme superfamily from archaea to bacteria and eukaryotes.

  • Organizational Affiliation

    Division of Respiratory and Critical Care Medicine, State Key Laboratory of Biotherapy, West China Hospital of Sichuan University and Collaborative Innovation Center of Biotherapy, Chengdu, Sichuan 610041, China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CDP-archaeol synthase182Aeropyrum pernix K1Mutation(s): 0
Gene Names: carSAPE_0433
Membrane Entity: Yes
Find proteins for Q9YF05 (Aeropyrum pernix (strain ATCC 700893 / DSM 11879 / JCM 9820 / NBRC 100138 / K1))
Explore Q9YF05
Go to UniProtKB:  Q9YF05
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9YF05
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.40 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.207
  • R-Value Observed: 0.211
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.505α = 90
b = 89.249β = 90
c = 98.876γ = 90
Software Package:
Software NamePurpose
HKL-3000data processing
Aimlessdata reduction
XDSdata extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Natural Science Foundation of ChinaChina31570842

Revision History  (Full details and data files)

  • Version 1.0: 2017-10-11
    Type: Initial release
  • Version 1.1: 2017-12-06
    Changes: Database references
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references, Derived calculations
