5FJO | pdb_00005fjo

N-acyl amino acid racemase from Amycolatopsis sp. Ts-1-60: G291D- F323Y mutant in complex with N-acetyl naphthylalanine

• PDB DOI: https://doi.org/10.2210/pdb5FJO/pdb

• Classification: LYASE
• Organism(s): Amycolatopsis sp.
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2015-10-12 Released: 2016-11-16
• Deposition Author(s): Sanchez-Carron, G., Campopiano, D., Grogan, G.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.08 Å
• R-Value Free:
  0.175 (Depositor), 0.185 (DCC)
• R-Value Work:
  0.145 (Depositor), 0.158 (DCC)
• R-Value Observed:
  0.146 (Depositor)

Starting Model: experimental

Literature

Structure of N-Acylamino Acid Racemase Mutants in Complex with Substrates

Sanchez-Carron, G., Campopiano, D., Grogan, G.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D4  (Explore in 3D)
Global Stoichiometry: Homo 8-mer - A8

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 79.61 kDa
• Atom Count: 6,463
• Modeled Residue Count: 735
• Deposited Residue Count: 736
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
N-succinylamino acid racemase	A, B	368	Amycolatopsis sp.	Mutation(s): 2  Gene Names: Aaar EC: 5.1.1 (PDB Primary Data), 4.2.1.113 (PDB Primary Data)
UniProt
Find proteins for Q44244 (Amycolatopsis sp) Explore Q44244  Go to UniProtKB:  Q44244

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NPQ	C [auth A], E [auth B]	N-acetyl naphthylalanine C15 H15 N O3 HGTIILKZSFKZMS-AWEZNQCLSA-N
MG	D [auth A], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.08 Å
• R-Value Free:  0.175 (Depositor), 0.185 (DCC)
• R-Value Work:  0.145 (Depositor), 0.158 (DCC)
• R-Value Observed: 0.146 (Depositor)

Space Group: I 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 164.71	α = 90
b = 164.71	β = 90
c = 169.59	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
SCALA	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2016-11-16
Deposition Author(s): Sanchez-Carron, G., Campopiano, D., Grogan, G.

Revision History

• Version 1.0: 2016-11-16
  Type: Initial release

• Version 1.1: 2024-01-10
  Changes: Data collection, Database references, Derived calculations, Other, Refinement description, Source and taxonomy, Structure summary
