Biological Assembly 1

 3D View: Structure | Electron Density | Validation Report | Ligand Interaction

Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 8-mer - A5B3 Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Hetero 8-mer - A2B2C2D2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: native gel electrophoresis

Macromolecule Content

• Total Structure Weight: 201.63 kDa
• Atom Count: 12005
• Modelled Residue Count: 1047
• Deposited Residue Count: 1302
• Unique protein chains: 4
• Unique nucleic acid chains: 1

5Z30

The crystal structure of the nucleosome containing a cancer-associated histone H2A.Z R80C mutant

• DOI: 10.2210/pdb5Z30/pdb
• NDB: 5Z30

• Classification: DNA BINDING PROTEIN/DNA
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3), Escherichia coli, Escherichia coli DH5[alpha]
• Mutation(s): Yes


• Deposited: 2018-01-05 Released: 2018-07-18
• Deposition Author(s): Horikoshi, N., Arimura, Y., Kurumizaka, H.
• Funding Organization(s): Japan Society for the Promotion of Science, Japan Science and Technology, Japan Agency for Medical Research and Development

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.45 Å
• R-Value Free: 0.243
• R-Value Work: 0.202
• R-Value Observed: 0.204

Literature

Cancer-associated mutations of histones H2B, H3.1 and H2A.Z.1 affect the structure and stability of the nucleosome.

Arimura, Y., Ikura, M., Fujita, R., Noda, M., Kobayashi, W., Horikoshi, N., Sun, J., Shi, L., Kusakabe, M., Harata, M., Ohkawa, Y., Tashiro, S., Kimura, H., Ikura, T., Kurumizaka, H.

(2018) Nucleic Acids Res 46: 10007-10018

• PubMed: 30053102
• DOI: 10.1093/nar/gky661
• Primary Citation of Related Structures:
  5Y0C, 5Y0D, 5Z30


• PubMed Abstract:


Mutations of the Glu76 residue of canonical histone H2B are frequently found in cancer cells. However, it is quite mysterious how a single amino acid substitution in one of the multiple H2B genes affects cell fate. Here we found that the H2B E76K mutation, in which Glu76 is replaced by Lys (E76K), distorted the interface between H2B and H4 in the nucleosome, as revealed by the crystal structure and induced nucleosome instability in vivo and in vitro. Exogenous production of the H2B E76K mutant robustly enhanced the colony formation ability of the expressing cells, indicating that the H2B E76K mutant has the potential to promote oncogenic transformation in the presence of wild-type H2B. We found that other cancer-associated mutations of histones, H3.1 E97K and H2A.Z.1 R80C, also induced nucleosome instability. Interestingly, like the H2B E76K mutant, the H3.1 E97K mutant was minimally incorporated into chromatin in cells, but it enhanced the colony formation ability. In contrast, the H2A.Z.1 R80C mutant was incorporated into chromatin in cells, and had minor effects on the colony formation ability of the cells. These characteristics of histones with cancer-associated mutations may provide important information toward understanding how the mutations promote cancer progression.

---

Organizational Affiliation:

Laboratory of Structural Biology, Graduate School of Advanced Science and Engineering, Waseda University, 2-2 Wakamatsu-cho, Shinjuku-ku, Tokyo 162-8480, Japan.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H3.1	A, E	139	Homo sapiens	Mutation(s): 0  Gene Names:  HIST1H3A, H3FA, HIST1H3B, H3FL, HIST1H3C, H3FC, HIST1H3D, H3FB, HIST1H3E, H3FD, HIST1H3F, H3FI, HIST1H3G, H3FH, HIST1H3H, H3FK, HIST1H3I, H3FF, HIST1H3J, H3FJ, H3C1, H3C2, H3C3, H3FC HIST1H3C, H3C4, H3C6, H3C7, H3C8, H3C10, H3C11, H3C12
UniProt & NIH Common Fund Data Resources
Find proteins for P68431 (Homo sapiens) Explore P68431  Go to UniProtKB:  P68431
PHAROS:  P68431 GTEx:  ENSG00000197409ENSG00000197153ENSG00000278828ENSG00000275714ENSG00000273983ENSG00000274750ENSG00000275379ENSG00000277775

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H4	B, F	106	Homo sapiens	Mutation(s): 0  Gene Names:  HIST1H4A, H4/A, H4FA, HIST1H4B, H4/I, H4FI, HIST1H4C, H4/G, H4FG, HIST1H4D, H4/B, H4FB, HIST1H4E, H4/J, H4FJ, HIST1H4F, H4/C, H4FC, HIST1H4H, H4/H, H4FH, HIST1H4I, H4/M, H4FM, HIST1H4J, H4/E, H4FE, HIST1H4K, H4/D, H4FD, HIST1H4L, H4/K, H4FK, HIST2H4A, H4/N, H4F2, H4FN, HIST2H4, HIST2H4B, H4/O, H4FO, HIST4H4, H4C1, H4C2, H4C3, H4C4, H4C5, H4C6, H4C8, H4C9, H4C11, H4C12, H4C13, H4C14, H4C15, H4-16
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens) Explore P62805  Go to UniProtKB:  P62805
PHAROS:  P62805 GTEx:  ENSG00000274618ENSG00000197238ENSG00000197837ENSG00000158406ENSG00000278705ENSG00000197061ENSG00000270882ENSG00000270276ENSG00000273542ENSG00000277157ENSG00000276966ENSG00000276180ENSG00000278637ENSG00000275126

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2A.Z	C, G	131	Homo sapiens	Mutation(s): 1  Gene Names: H2AFZ, H2AZ, H2AZ1
UniProt & NIH Common Fund Data Resources
Find proteins for P0C0S5 (Homo sapiens) Explore P0C0S5  Go to UniProtKB:  P0C0S5
PHAROS:  P0C0S5 GTEx:  ENSG00000164032

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2B type 1-J	D, H	129	Homo sapiens	Mutation(s): 0  Gene Names: HIST1H2BJ, H2BFR, H2BC11
UniProt & NIH Common Fund Data Resources
Find proteins for P06899 (Homo sapiens) Explore P06899  Go to UniProtKB:  P06899
PHAROS:  P06899 GTEx:  ENSG00000124635

Entity ID: 5
Molecule	Chains	Length	Organism	Image
DNA (146-MER)	I, J	146	Homo sapiens

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MN	L [auth E], N [auth I], O [auth I], P [auth I], Q [auth I], R [auth J], S [auth J], T [auth J], U [auth J], V [auth J], W [auth J]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N
CL	K [auth A], M [auth E]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.45 Å
• R-Value Free: 0.243
• R-Value Work: 0.202
• R-Value Observed: 0.204
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 99.399	α = 90
b = 108.332	β = 90
c = 170.902	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2018-01-05
• Released Date: 2018-07-18
Deposition Author(s): Horikoshi, N., Arimura, Y., Kurumizaka, H.

---

Funding Organization	Location	Grant Number
Japan Society for the Promotion of Science	Japan	JP25116002
Japan Society for the Promotion of Science	Japan	JP17H01408
Japan Society for the Promotion of Science	Japan	JP17K15043
Japan Science and Technology	Japan	JPMJCR16G1
Japan Agency for Medical Research and Development	Japan	Platform Project for Supporting Drug Discovery and Life Science Research

Revision History

• Version 1.0: 2018-07-18
  Type: Initial release

• Version 1.1: 2018-08-29
  Changes: Data collection, Database references
• Version 1.2: 2018-11-21
  Changes: Data collection, Database references
