5YPZ

Crystal structure of minor pilin CofB from CFA/III complexed with N-terminal peptide fragment of CofJ


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.52 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.192
  • R-Value Observed: 0.196

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Interplay of a secreted protein with type IVb pilus for efficient enterotoxigenicEscherichia colicolonization.

Oki, H.Kawahara, K.Maruno, T.Imai, T.Muroga, Y.Fukakusa, S.Iwashita, T.Kobayashi, Y.Matsuda, S.Kodama, T.Iida, T.Yoshida, T.Ohkubo, T.Nakamura, S.

(2018) Proc Natl Acad Sci U S A 115: 7422-7427

  • DOI: https://doi.org/10.1073/pnas.1805671115
  • Primary Citation of Related Structures:
    5YPZ, 5YQ0

  • PubMed Abstract:

    Initial attachment and subsequent colonization of the intestinal epithelium comprise critical events allowing enteric pathogens to survive and express their pathogenesis. In enterotoxigenic Escherichia coli (ETEC), these are mediated by a long proteinaceous fiber termed type IVb pilus (T4bP). We have reported that the colonization factor antigen/III (CFA/III), an operon-encoded T4bP of ETEC, possesses a minor pilin, CofB, that carries an H-type lectin domain at its tip. Although CofB is critical for pilus assembly by forming a trimeric initiator complex, its importance for bacterial attachment remains undefined. Here, we show that T4bP is not sufficient for bacterial attachment, which also requires a secreted protein CofJ, encoded within the same CFA/III operon. The crystal structure of CofB complexed with a peptide encompassing the binding region of CofJ showed that CofJ interacts with CofB by anchoring its flexible N-terminal extension to be embedded deeply into the expected carbohydrate recognition site of the CofB H-type lectin domain. By combining this structure and physicochemical data in solution, we built a plausible model of the CofJ-CFA/III pilus complex, which suggested that CofJ acts as a molecular bridge by binding both T4bP and the host cell membrane. The Fab fragments of a polyclonal antibody against CofJ significantly inhibited bacterial attachment by preventing the adherence of secreted CofJ proteins. These findings signify the interplay between T4bP and a secreted protein for attaching to and colonizing the host cell surface, potentially constituting a therapeutic target against ETEC infection.


  • Organizational Affiliation

    Graduate School of Pharmaceutical Sciences, Osaka University, Suita, 565-0871 Osaka, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CofB
A, B, C
492Escherichia coliMutation(s): 0
Gene Names: cofB
UniProt
Find proteins for Q93I73 (Escherichia coli)
Explore Q93I73
Go to UniProtKB:  Q93I73
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93I73
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
CofJ
D, E, F
24Escherichia coliMutation(s): 0
UniProt
Find proteins for Q93I65 (Escherichia coli)
Explore Q93I65
Go to UniProtKB:  Q93I65
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93I65
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.52 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.192
  • R-Value Observed: 0.196
  • Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 157.216α = 90
b = 157.216β = 90
c = 118.132γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2018-06-27
    Type: Initial release
  • Version 1.1: 2018-07-18
    Changes: Data collection, Database references
  • Version 1.2: 2018-07-25
    Changes: Data collection, Database references
  • Version 1.3: 2023-11-22
    Changes: Data collection, Database references, Refinement description
