5YE4 | pdb_00005ye4

Crystal structure of the complex of di-acetylated histone H4 and 1A9D7 Fab fragment

PDB DOI: https://doi.org/10.2210/pdb5YE4/pdb

Classification: NUCLEAR PROTEIN
Organism(s): Mus musculus, Homo sapiens
Expression System: Mus musculus
Mutation(s): No

Deposited: 2017-09-15 Released: 2018-08-22
Deposition Author(s): Matsuda, T., Ito, T., Wakamori, M., Umehara, T.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.224 (Depositor), 0.220 (DCC)
R-Value Work:
0.194 (Depositor), 0.190 (DCC)
R-Value Observed:
0.194 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

JQ1 affects BRD2-dependent and independent transcription regulation without disrupting H4-hyperacetylated chromatin states.

Handoko, L., Kaczkowski, B., Hon, C.C., Lizio, M., Wakamori, M., Matsuda, T., Ito, T., Jeyamohan, P., Sato, Y., Sakamoto, K., Yokoyama, S., Kimura, H., Minoda, A., Umehara, T.

(2018) Epigenetics 13: 410-431

PubMed: 30080437 Search on PubMedSearch on PubMed Central
DOI: https://doi.org/10.1080/15592294.2018.1469891
Primary Citation of Related Structures:
5YE3, 5YE4

PubMed Abstract:
The bromodomain and extra-terminal domain (BET) proteins are promising drug targets for cancer and immune diseases. However, BET inhibition effects have been studied more in the context of bromodomain-containing protein 4 (BRD4) than BRD2, and the BET protein association to histone H4-hyperacetylated chromatin is not understood at the genome-wide level. Here, we report transcription start site (TSS)-resolution integrative analyses of ChIP-seq and transcriptome profiles in human non-small cell lung cancer (NSCLC) cell line H23. We show that di-acetylation at K5 and K8 of histone H4 (H4K5acK8ac) co-localizes with H3K27ac and BRD2 in the majority of active enhancers and promoters, where BRD2 has a stronger association with H4K5acK8ac than H3K27ac. Although BET inhibition by JQ1 led to complete reduction of BRD2 binding to chromatin, only local changes of H4K5acK8ac levels were observed, suggesting that recruitment of BRD2 does not influence global histone H4 hyperacetylation levels. This finding supports a model in which recruitment of BET proteins via histone H4 hyperacetylation is predominant over hyperacetylation of histone H4 by BET protein-associated acetyltransferases. In addition, we found that a remarkable number of BRD2-bound genes, including MYC and its downstream target genes, were transcriptionally upregulated upon JQ1 treatment. Using BRD2-enriched sites and transcriptional activity analysis, we identified candidate transcription factors potentially involved in the JQ1 response in BRD2-dependent and -independent manner.

Organizational Affiliation

a Division of Genomic Technologies , RIKEN Center for Life Science Technologies, Yokohama , Kanagawa , Japan.

Macromolecule Content

Total Structure Weight: 96.83 kDa
Atom Count: 7,414
Modelled Residue Count: 860
Deposited Residue Count: 872
Unique protein chains: 3

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
1A9D7 VH CH1 chain	A, C	211	Mus musculus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
1A9D7 L chain	B, D	213	Mus musculus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
di-acetylated histone H4	E, F	12	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens) Explore P62805 Go to UniProtKB: P62805
PHAROS: P62805 GTEx: ENSG00000274618 ENSG00000197238 ENSG00000197837 ENSG00000158406 ENSG00000278705 ENSG00000197061 ENSG00000270882 ENSG00000270276 ENSG00000273542 ENSG00000277157 ENSG00000276966 ENSG00000276180 ENSG00000278637 ENSG00000275126
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P62805
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain AA [auth D] SDF format, chain BA [auth D] SDF format, chain CA [auth D] SDF format, chain DA [auth D] SDF format, chain EA [auth D] SDF format, chain FA [auth D] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth C] SDF format, chain V [auth C] SDF format, chain W [auth D] SDF format, chain X [auth D] SDF format, chain Y [auth D] SDF format, chain Z [auth D] MOL2 format, chain AA [auth D] MOL2 format, chain BA [auth D] MOL2 format, chain CA [auth D] MOL2 format, chain DA [auth D] MOL2 format, chain EA [auth D] MOL2 format, chain FA [auth D] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth C] MOL2 format, chain V [auth C] MOL2 format, chain W [auth D] MOL2 format, chain X [auth D] MOL2 format, chain Y [auth D] MOL2 format, chain Z [auth D] mmCIF format, chain AA [auth D] mmCIF format, chain BA [auth D] mmCIF format, chain CA [auth D] mmCIF format, chain DA [auth D] mmCIF format, chain EA [auth D] mmCIF format, chain FA [auth D] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth C] mmCIF format, chain V [auth C] mmCIF format, chain W [auth D] mmCIF format, chain X [auth D] mmCIF format, chain Y [auth D] mmCIF format, chain Z [auth D]	AA [auth D] BA [auth D] CA [auth D] DA [auth D] EA [auth D] AA [auth D], BA [auth D], CA [auth D], DA [auth D], EA [auth D], FA [auth D], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth C], V [auth C], W [auth D], X [auth D], Y [auth D], Z [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain AA [auth D] Focus chain BA [auth D] Focus chain CA [auth D] Focus chain DA [auth D] Focus chain EA [auth D] Focus chain FA [auth D] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth C] Focus chain V [auth C] Focus chain W [auth D] Focus chain X [auth D] Focus chain Y [auth D] Focus chain Z [auth D] Interactions & Density Focus chain AA [auth D] Focus chain BA [auth D] Focus chain CA [auth D] Focus chain DA [auth D] Focus chain EA [auth D] Focus chain FA [auth D] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth C] Focus chain V [auth C] Focus chain W [auth D] Focus chain X [auth D] Focus chain Y [auth D] Focus chain Z [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
ALY Query on ALY	E, F	L-PEPTIDE LINKING	C₈ H₁₆ N₂ O₃		LYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.224 (Depositor), 0.220 (DCC)
R-Value Work: 0.194 (Depositor), 0.190 (DCC)
R-Value Observed: 0.194 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 39.346	α = 90
b = 164.093	β = 104.5
c = 73.7	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2018-08-22

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-08-22
Type: Initial release
Version 1.1: 2018-09-19
Changes: Data collection, Database references
Version 1.2: 2023-11-22
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 1.3: 2024-11-06
Changes: Structure summary
