5Y1J | pdb_00005y1j

Crystal structure of human FXR in complex with a functional drug ligand

• PDB DOI: https://doi.org/10.2210/pdb5Y1J/pdb

• Classification: NUCLEAR PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-07-20 Released: 2018-10-31
• Deposition Author(s): Lu, Y., Li, Y.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.238 (Depositor), 0.240 (DCC)
• R-Value Work:
  0.194 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.196 (Depositor)

Literature

Crystal structure of human FXR in complex with a functional drug liagnd

Lu, Y., Li, Y.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 28.19 kDa
• Atom Count: 2,074
• Modeled Residue Count: 236
• Deposited Residue Count: 238
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bile acid receptor	A	228	Homo sapiens	Mutation(s): 0  Gene Names: NR1H4, BAR, FXR, HRR1, RIP14
UniProt & NIH Common Fund Data Resources
Find proteins for Q96RI1 (Homo sapiens) Explore Q96RI1  Go to UniProtKB:  Q96RI1
PHAROS:  Q96RI1 GTEx:  ENSG00000012504

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptide from Nuclear receptor coactivator 2	B [auth U]	10	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q15596 (Homo sapiens) Explore Q15596  Go to UniProtKB:  Q15596
PHAROS:  Q15596 GTEx:  ENSG00000140396

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
D5H (Subject of Investigation/LOI)	C [auth A]	2-[[2-fluoranyl-4-(3-methoxyphenyl)phenyl]carbamoyl]cyclopentene-1-carboxylic acid C20 H18 F N O4 XPRDUGXOWVXZLL-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
D5H	BindingDB:  5Y1J	EC50: min: 450, max: 1.00e+4 (nM) from 2 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.238 (Depositor), 0.240 (DCC)
• R-Value Work:  0.194 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.196 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.668	α = 90
b = 162.046	β = 90
c = 115.619	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
PHENIX	model building
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-10-31
Deposition Author(s): Lu, Y., Li, Y.

Revision History

• Version 1.0: 2018-10-31
  Type: Initial release

• Version 1.1: 2024-03-27
  Changes: Data collection, Database references
