5WBW

Yeast Hsp104 fragment 1-360


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.237
  • R-Value Observed: 0.241

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural determinants for protein unfolding and translocation by the Hsp104 protein disaggregase.

Lee, J.Sung, N.Yeo, L.Chang, C.Lee, S.Tsai, F.T.F.

(2017) Biosci Rep 37

  • DOI: https://doi.org/10.1042/BSR20171399
  • Primary Citation of Related Structures:
    5WBW

  • PubMed Abstract:

    The ring-forming Hsp104 ATPase cooperates with Hsp70 and Hsp40 molecular chaperones to rescue stress-damaged proteins from both amorphous and amyloid-forming aggregates. The ability to do so relies upon pore loops present in the first ATP-binding domain (AAA-1; loop-1 and loop-2 ) and in the second ATP-binding domain (AAA-2; loop-3) of Hsp104, which face the protein translocating channel and couple ATP-driven changes in pore loop conformation to substrate translocation. A hallmark of loop-1 and loop-3 is an invariable and mutational sensitive aromatic amino acid (Tyr 257 and Tyr 662 ) involved in substrate binding. However, the role of conserved aliphatic residues (Lys 256 , Lys 258 , and Val 663 ) flanking the pore loop tyrosines, and the function of loop-2 in protein disaggregation has not been investigated. Here we present the crystal structure of an N-terminal fragment of Saccharomyces cerevisiae Hsp104 exhibiting molecular interactions involving both AAA-1 pore loops, which resemble contacts with bound substrate. Corroborated by biochemical experiments and functional studies in yeast, we show that aliphatic residues flanking Tyr 257 and Tyr 662 are equally important for substrate interaction, and abolish Hsp104 function when mutated to glycine. Unexpectedly, we find that loop-2 is sensitive to aspartate substitutions that impair Hsp104 function and abolish protein disaggregation when loop-2 is replaced by four aspartate residues. Our observations suggest that Hsp104 pore loops have non-overlapping functions in protein disaggregation and together coordinate substrate binding, unfolding, and translocation through the Hsp104 hexamer.


  • Organizational Affiliation

    Verna and Marrs McLean Department of Biochemistry and Molecular Biology, Baylor College of Medicine, One Baylor Plaza, Houston, TX 77030, U.S.A.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Heat shock protein 104A,
B,
C [auth D]
353Saccharomyces cerevisiaeMutation(s): 0
Gene Names: HSP104YLL026WL0948
UniProt
Find proteins for P31539 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P31539
Go to UniProtKB:  P31539
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP31539
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.286
  • R-Value Work: 0.237
  • R-Value Observed: 0.241
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.556α = 90
b = 75.824β = 90
c = 235.649γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
REFMACphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Released Date: 2018-01-03
  • Deposition Author(s): Lee, S.

Revision History  (Full details and data files)

  • Version 1.0: 2018-01-03
    Type: Initial release
  • Version 1.1: 2024-03-13
    Changes: Data collection, Database references
