5VEF

PAK4 kinase domain in complex with fasudil


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.200
  • R-Value Observed: 0.202

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

PAK4 crystal structures suggest unusual kinase conformational movements.

Zhang, E.Y.Ha, B.H.Boggon, T.J.

(2018) Biochim Biophys Acta 1866: 356-365

  • DOI: 10.1016/j.bbapap.2017.10.004
  • Primary Citation of Related Structures:
    5VEE, 5VED, 5VEF

  • PubMed Abstract:
  • In order for protein kinases to exchange nucleotide they must open and close their catalytic cleft. These motions are associated with rotations of the N-lobe, predominantly around the 'hinge region'. We conducted an analysis of 28 crystal structures ...

    In order for protein kinases to exchange nucleotide they must open and close their catalytic cleft. These motions are associated with rotations of the N-lobe, predominantly around the 'hinge region'. We conducted an analysis of 28 crystal structures of the serine-threonine kinase, p21-activated kinase 4 (PAK4), including three newly determined structures in complex with staurosporine, FRAX486, and fasudil (HA-1077). We find an unusual motion between the N-lobe and C-lobe of PAK4 that manifests as a partial unwinding of helix αC. Principal component analysis of the crystal structures rationalizes these movements into three major states, and analysis of the kinase hydrophobic spines indicates concerted movements that create an accessible back pocket cavity. The conformational changes that we observe for PAK4 differ from previous descriptions of kinase motions, and although we observe these differences in crystal structures there is the possibility that the movements observed may suggest a diversity of kinase conformational changes associated with regulation.


    Organizational Affiliation

    Department of Molecular Biophysics and Biochemistry, Yale University School of Medicine, 333 Cedar St., New Haven, CT 06520, United States; Department of Pharmacology, Yale University School of Medicine, 333 Cedar St., New Haven, CT 06520, United States. Electronic address: titus.boggon@yale.edu.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Serine/threonine-protein kinase PAK 4A319Homo sapiensMutation(s): 0
Gene Names: PAK4KIAA1142
EC: 2.7.11.1
Find proteins for O96013 (Homo sapiens)
Explore O96013
Go to UniProtKB:  O96013
NIH Common Fund Data Resources
PHAROS  O96013
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
M77
Query on M77

Download CCD File
A
5-(1,4-DIAZEPAN-1-SULFONYL)ISOQUINOLINE
C14 H17 N3 O2 S
NGOGFTYYXHNFQH-UHFFFAOYSA-N
 Ligand Interaction
ACT
Query on ACT

Download CCD File
A
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
SEP
Query on SEP
AL-PEPTIDE LINKINGC3 H8 N O6 PSER
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.75 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.200
  • R-Value Observed: 0.202
  • Space Group: P 41 21 2
  • Diffraction Data DOI: 10.15785/SBGRID/494 SBGrid
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 61.94α = 90
b = 61.94β = 90
c = 182.741γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM102262
National Institutes of Health/Office of the DirectorUnited StatesS10OD018007

Revision History

  • Version 1.0: 2017-10-18
    Type: Initial release
  • Version 1.1: 2018-01-03
    Changes: Database references
  • Version 1.2: 2020-01-01
    Changes: Author supporting evidence
  • Version 1.3: 2020-02-26
    Changes: Data collection
