5TVL | pdb_00005tvl

Crystal structure of foldase protein PrsA from Streptococcus pneumoniae str. Canada MDR_19A

PDB DOI: https://doi.org/10.2210/pdb5TVL/pdb

Classification: ISOMERASE
Organism(s): Streptococcus pneumoniae str. Canada MDR_19A
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2016-11-09 Released: 2016-11-23
Deposition Author(s): Borek, D., Yim, V., Kudritska, M., Wawrzak, Z., Stogios, P.J., Otwinowski, Z., Savchenko, A., Anderson, W., Center for Structural Genomics of Infectious Diseases (CSGID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.55 Å
R-Value Free:
0.297 (Depositor), 0.300 (DCC)
R-Value Work:
0.225 (Depositor), 0.230 (DCC)
R-Value Observed:
0.229 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 2.1 of the entry. See complete history.

Literature

Crystal structure of foldase protein PrsA from Streptococcus pneumoniae str. Canada MDR_19A

Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 128.74 kDa
Atom Count: 8,647
Modeled Residue Count: 1,068
Deposited Residue Count: 1,148
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Foldase protein PrsA	A, B, C, D	287	Streptococcus pneumoniae str. Canada MDR_19A	Mutation(s): 0 Gene Names: prsA, SPH_1082 EC: 5.2.1.8
UniProt
Find proteins for B1IBE1 (Streptococcus pneumoniae (strain Hungary19A-6)) Explore B1IBE1 Go to UniProtKB: B1IBE1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B1IBE1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain F [auth A] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain F [auth A] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain F [auth A]	F [auth A], K [auth B], L [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B] Interactions & Density Focus chain F [auth A] Focus chain K [auth B] Focus chain L [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain U [auth D] SDF format, chain T [auth D] SDF format, chain S [auth D] SDF format, chain Q [auth C] SDF format, chain P [auth C] SDF format, chain M [auth B] SDF format, chain G [auth A] MOL2 format, chain U [auth D] MOL2 format, chain T [auth D] MOL2 format, chain S [auth D] MOL2 format, chain Q [auth C] MOL2 format, chain P [auth C] MOL2 format, chain M [auth B] MOL2 format, chain G [auth A] mmCIF format, chain U [auth D] mmCIF format, chain T [auth D] mmCIF format, chain S [auth D] mmCIF format, chain Q [auth C] mmCIF format, chain P [auth C] mmCIF format, chain M [auth B] mmCIF format, chain G [auth A]	G [auth A] M [auth B] P [auth C] Q [auth C] S [auth D] G [auth A], M [auth B], P [auth C], Q [auth C], S [auth D], T [auth D], U [auth D]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain M [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain S [auth D] Focus chain T [auth D] Focus chain U [auth D] Interactions & Density Focus chain G [auth A] Focus chain M [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain S [auth D] Focus chain T [auth D] Focus chain U [auth D]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain N [auth C] SDF format, chain R [auth D] SDF format, chain O [auth C] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain E [auth A] MOL2 format, chain N [auth C] MOL2 format, chain R [auth D] MOL2 format, chain O [auth C] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain E [auth A] mmCIF format, chain N [auth C] mmCIF format, chain R [auth D] mmCIF format, chain O [auth C] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain E [auth A]	E [auth A] H [auth B] I [auth B] J [auth B] N [auth C] E [auth A], H [auth B], I [auth B], J [auth B], N [auth C], O [auth C], R [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain R [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain R [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.55 Å
R-Value Free: 0.297 (Depositor), 0.300 (DCC)
R-Value Work: 0.225 (Depositor), 0.230 (DCC)
R-Value Observed: 0.229 (Depositor)

Diffraction Data: https://doi.org/10.18430/m35tvl

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.315	α = 90
b = 70.94	β = 91.49
c = 116.626	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2016-11-23

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Revision History (Full details and data files)

Version 1.0: 2016-11-23
Type: Initial release
Version 1.1: 2016-11-30
Changes: Structure summary
Version 2.0: 2021-02-17
Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Structure summary
Version 2.1: 2024-03-06
Changes: Data collection, Database references
