5TSB

Crystal structure of the Zrt-/Irt-like protein from Bordetella bronchiseptica with bound Cd2+


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.227

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal structures of a ZIP zinc transporter reveal a binuclear metal center in the transport pathway.

Zhang, T.Liu, J.Fellner, M.Zhang, C.Sui, D.Hu, J.

(2017) Sci Adv 3: e1700344-e1700344

  • DOI: 10.1126/sciadv.1700344
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Zrt/Irt-like proteins (ZIPs) play fundamental roles in metal metabolism/homeostasis and are broadly involved in numerous physiological and pathological processes. The lack of high-resolution structure of the ZIPs hinders understanding of the metal tr ...

    Zrt/Irt-like proteins (ZIPs) play fundamental roles in metal metabolism/homeostasis and are broadly involved in numerous physiological and pathological processes. The lack of high-resolution structure of the ZIPs hinders understanding of the metal transport mechanism. We report two crystal structures of a prokaryotic ZIP in lipidic cubic phase with bound metal substrates (Cd2+ at 2.7 Å and Zn2+ at 2.4 Å). The structures revealed a novel 3+2+3TM architecture and an inward-open conformation occluded at the extracellular side. Two metal ions were trapped halfway through the membrane, unexpectedly forming a binuclear metal center. The Zn2+-substituted structure suggested asymmetric functions of the two metal-binding sites and also revealed a route for zinc release. Mapping of disease-causing mutations, structure-guided mutagenesis, and cell-based zinc transport assay demonstrated the crucial role of the binuclear metal center for human ZIP4. A metal transport mechanism for the ZIP from Bordetella bronchiseptica was proposed, which is likely applicable to other ZIPs.


    Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Michigan State University, East Lansing, MI 48824, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Membrane protein
A
309Bordetella bronchiseptica (strain ATCC BAA-588 / NCTC 13252 / RB50)Mutation(s): 0
Find proteins for A0A0H3LM39 (Bordetella bronchiseptica (strain ATCC BAA-588 / NCTC 13252 / RB50))
Go to UniProtKB:  A0A0H3LM39
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CD
Query on CD

Download SDF File
Download CCD File
A
CADMIUM ION
Cd
WLZRMCYVCSSEQC-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.7 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.227
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 96.076α = 90.00
b = 61.596β = 108.74
c = 54.870γ = 90.00
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
SOLVEphasing
HKL-2000data reduction
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical SciencesUnited StatesR01GM115373

Revision History

  • Version 1.0: 2017-09-20
    Type: Initial release
  • Version 1.1: 2017-09-27
    Type: Author supporting evidence
