5OOY | pdb_00005ooy

Designed Ankyrin Repeat Protein (DARPin) VHAH-1 in complex with Lysozyme

• PDB DOI: https://doi.org/10.2210/pdb5OOY/pdb

• Classification: DE NOVO PROTEIN
• Organism(s): synthetic construct, Gallus gallus
• Expression System: Escherichia coli M15
• Mutation(s): No


• Deposited: 2017-08-09 Released: 2018-08-29
• Deposition Author(s): Hogan, B.J., Fischer, G., Houlihan, G., Edmond, S., Huovinen, T.T.K., Hollfelder, F., Hyvonen, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.72 Å
• R-Value Free:
  0.224 (Depositor), 0.230 (DCC)
• R-Value Work:
  0.192 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.194 (Depositor)

Starting Model: experimental

Literature

Designed Ankyrin Repeat Protein (DARPin) VHAH-1 in complex with Lysozyme

Hogan, B.J., Hyvonen, M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 64.96 kDa
• Atom Count: 4,814
• Modeled Residue Count: 575
• Deposited Residue Count: 594
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DARPin VHAH-1	A, C [auth E]	168	synthetic construct	Mutation(s): 0

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysozyme C	B, D [auth F]	129	Gallus gallus	Mutation(s): 0  EC: 3.2.1.17
UniProt
Find proteins for P00698 (Gallus gallus) Explore P00698  Go to UniProtKB:  P00698

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.72 Å
• R-Value Free:  0.224 (Depositor), 0.230 (DCC)
• R-Value Work:  0.192 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.194 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.773	α = 90
b = 81.052	β = 94.01
c = 89.387	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2018-08-29
Deposition Author(s): Hogan, B.J., Fischer, G., Houlihan, G., Edmond, S., Huovinen, T.T.K., Hollfelder, F., Hyvonen, M.

Revision History

• Version 1.0: 2018-08-29
  Type: Initial release

• Version 1.1: 2024-01-17
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2024-10-16
  Changes: Structure summary
