5ODL

Single-stranded DNA-binding protein from bacteriophage Enc34 in complex with ssDNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.56 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.141

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural Basis for DNA Recognition of a Single-stranded DNA-binding Protein from Enterobacter Phage Enc34.

Cernooka, E.Rumnieks, J.Tars, K.Kazaks, A.

(2017) Sci Rep 7: 15529-15529

  • DOI: 10.1038/s41598-017-15774-y
  • Primary Citation of Related Structures:  5ODJ, 5ODK

  • PubMed Abstract:
  • Modern DNA sequencing capabilities have led to the discovery of a large number of new bacteriophage genomes, which are a rich source of novel proteins with an unidentified biological role. The genome of Enterobacter cancerogenus bacteriophage Enc34 c ...

    Modern DNA sequencing capabilities have led to the discovery of a large number of new bacteriophage genomes, which are a rich source of novel proteins with an unidentified biological role. The genome of Enterobacter cancerogenus bacteriophage Enc34 contains several proteins of unknown function that are nevertheless conserved among distantly related phages. Here, we report the crystal structure of a conserved Enc34 replication protein ORF6 which contains a domain of unknown function DUF2815. Despite the low (~15%) sequence identity, the Enc34 ORF6 structurally resembles the gene 2.5 protein from bacteriophage T7, and likewise is a single-stranded DNA (ssDNA)-binding protein (SSB) that consists of a variation of the oligosaccharide/oligonucleotide-binding (OB)-fold and an unstructured C-terminal segment. We further report the crystal structure of a C-terminally truncated ORF6 in complex with an ssDNA oligonucleotide that reveals a DNA-binding mode involving two aromatic stacks and multiple electrostatic interactions, with implications for a common ssDNA recognition mechanism for all T7-type SSBs.


    Organizational Affiliation

    Latvian Biomedical Research and Study Centre, Riga, LV-1067, Latvia.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
single-stranded DNA-binding protein
A
180N/AN/A
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsLengthOrganism
oligo(T)D9synthetic construct
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.56 Å
  • R-Value Free: 0.191
  • R-Value Work: 0.141
  • Space Group: P 61
Unit Cell:
Length (Å)Angle (°)
a = 43.489α = 90.00
b = 43.489β = 90.00
c = 179.106γ = 120.00
Software Package:
Software NamePurpose
PHASERphasing
REFMACrefinement
SCALAdata scaling
iMOSFLMdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-10-25
    Type: Initial release
  • Version 1.1: 2017-11-29
    Type: Database references
