Crystal structure of Zn3-hUb(human ubiquitin) adduct from a solution 70 mM zinc acetate/20% v/v TFE/1.3 mM hUb

Experimental Data Snapshot

  • Resolution: 1.70 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.225
  • R-Value Observed: 0.227

wwPDB Validation   3D Report Full Report

This is version 1.4 of the entry. See complete history


Aggregation Pathways of Native-Like Ubiquitin Promoted by Single-Point Mutation, Metal Ion Concentration, and Dielectric Constant of the Medium.

Fermani, S.Calvaresi, M.Mangini, V.Falini, G.Bottoni, A.Natile, G.Arnesano, F.

(2018) Chemistry 24: 4140-4148

  • DOI: https://doi.org/10.1002/chem.201705543
  • Primary Citation of Related Structures:
    5NL4, 5NL5, 5NLF, 5NLI, 5NLJ, 5NMC

  • PubMed Abstract:

    Ubiquitin-positive protein aggregates are biomarkers of neurodegeneration, but the molecular mechanism responsible for their formation and accumulation is still unclear. Possible aggregation pathways of human ubiquitin (hUb) promoted by both intrinsic and extrinsic factors, are here investigated. By a computational analysis, two different hUb dimers are indicated as possible precursors of amyloid-like structures, but their formation is disfavored by an electrostatic repulsion involving Glu16 and other carboxylate residues present at the dimer interface. Experimental data on the E16V mutant of hUb shows that this single-point mutation, although not affecting the overall protein conformation, promotes protein aggregation. It is sufficient to shift the same mutation by only two residues (E18V) to regain the behavior of wild-type hUb. The neutralization of Glu16 negative charge by a metal ion and a decrease of the dielectric constant of the medium by addition of trifluoroethanol (TFE), also promote hUb aggregation. The outcomes of this research have important implications for the prediction of physiological parameters that favor aggregate formation.

  • Organizational Affiliation

    Department of Chemistry "Giacomo Ciamician", University of Bologna, via F. Selmi 2, 40126, Bologna, Italy.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B, C
76Homo sapiensMutation(s): 0
Gene Names: UBC
UniProt & NIH Common Fund Data Resources
Find proteins for P0CG48 (Homo sapiens)
Explore P0CG48
Go to UniProtKB:  P0CG48
GTEx:  ENSG00000150991
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0CG48
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on ZN

Download Ideal Coordinates CCD File
F [auth A]
G [auth A]
H [auth A]
I [auth A]
L [auth B]
F [auth A],
G [auth A],
H [auth A],
I [auth A],
L [auth B],
M [auth B],
O [auth C],
P [auth C],
Q [auth C]
Query on ACT

Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
J [auth B],
K [auth B],
N [auth C]
C2 H3 O2
Experimental Data & Validation

Experimental Data

  • Resolution: 1.70 Å
  • R-Value Free: 0.276
  • R-Value Work: 0.225
  • R-Value Observed: 0.227
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 43.79α = 90
b = 50.32β = 90
c = 93.95γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-05-03
    Type: Initial release
  • Version 1.1: 2017-12-06
    Changes: Database references
  • Version 1.2: 2018-01-03
    Changes: Database references
  • Version 1.3: 2018-03-28
    Changes: Database references
  • Version 1.4: 2024-01-17
    Changes: Data collection, Database references, Derived calculations, Refinement description
