5M8K

Crystal structure of Eremococcus coleocola manganese transporter mutant E129Q

• PDB DOI: https://doi.org/10.2210/pdb5M8K/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Eremococcus coleocola ACS-139-V-Col8
• Expression System: Escherichia coli
• Mutation(s): Yes
• Membrane Protein: Yes  PDBTMMemProtMDmpstruc


• Deposited: 2016-10-29 Released: 2017-01-11
• Deposition Author(s): Manatschal, C., Ehrnstorfer, I.A., Arnold, F.M., Laederach, J., Dutzler, R.
• Funding Organization(s): Swiss National Science Foundation

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.60 Å
• R-Value Free: 0.265
• R-Value Work: 0.221
• R-Value Observed: 0.223

Literature

Structural and mechanistic basis of proton-coupled metal ion transport in the SLC11/NRAMP family.

Ehrnstorfer, I.A., Manatschal, C., Arnold, F.M., Laederach, J., Dutzler, R.

(2017) Nat Commun 8: 14033-14033

• PubMed: 28059071
• DOI: https://doi.org/10.1038/ncomms14033
• Primary Citation of Related Structures:
  5M87, 5M8A, 5M8J, 5M8K


• PubMed Abstract:


  Secondary active transporters of the SLC11/NRAMP family catalyse the uptake of iron and manganese into cells. These proteins are highly conserved across all kingdoms of life and thus likely share a common transport mechanism. Here we describe the structural and functional properties of the prokaryotic SLC11 transporter EcoDMT. Its crystal structure reveals a previously unknown outward-facing state of the protein family. In proteoliposomes EcoDMT mediates proton-coupled uptake of manganese at low micromolar concentrations. Mutants of residues in the transition-metal ion-binding site severely affect transport, whereas a mutation of a conserved histidine located near this site results in metal ion transport that appears uncoupled to proton transport. Combined with previous results, our study defines the conformational changes underlying transition-metal ion transport in the SLC11 family and it provides molecular insight to its coupling to protons.

---

Organizational Affiliation:

Department of Biochemistry, University of Zurich, Winterthurerstrasse 190, 8057 Zurich, Switzerland.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 56.63 kDa
• Atom Count: 3,780
• Modelled Residue Count: 494
• Deposited Residue Count: 519
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Divalent metal cation transporter MntH	A	519	Eremococcus coleocola ACS-139-V-Col8	Mutation(s): 1  Gene Names: mntH, HMPREF9257_1603 Membrane Entity: Yes
UniProt
Find proteins for E4KPW4 (Eremococcus coleocola ACS-139-V-Col8) Explore E4KPW4  Go to UniProtKB:  E4KPW4

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.60 Å
• R-Value Free: 0.265
• R-Value Work: 0.221
• R-Value Observed: 0.223
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 151.26	α = 90
b = 81.77	β = 107.6
c = 96.5	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XDS	data scaling
PHENIX	refinement

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2017-01-11
Deposition Author(s): Manatschal, C., Ehrnstorfer, I.A., Arnold, F.M., Laederach, J., Dutzler, R.

---

Funding Organization	Location	Grant Number
Swiss National Science Foundation	Switzerland	--

Revision History

• Version 1.0: 2017-01-11
  Type: Initial release

• Version 1.1: 2017-01-18
  Changes: Database references
• Version 1.2: 2017-09-13
  Changes: Author supporting evidence
• Version 1.3: 2024-01-17
  Changes: Data collection, Database references, Refinement description
