5KTE

Crystal structure of Deinococcus radiodurans MntH, an Nramp-family transition metal transporter


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.941 Å
  • R-Value Free: 0.313
  • R-Value Work: 0.268

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Crystal Structure and Conformational Change Mechanism of a Bacterial Nramp-Family Divalent Metal Transporter.

Bozzi, A.T.Bane, L.B.Weihofen, W.A.Singharoy, A.Guillen, E.R.Ploegh, H.L.Schulten, K.Gaudet, R.

(2016) Structure 24: 2102-2114

  • DOI: 10.1016/j.str.2016.09.017

  • PubMed Abstract:
  • The widely conserved natural resistance-associated macrophage protein (Nramp) family of divalent metal transporters enables manganese import in bacteria and dietary iron uptake in mammals. We determined the crystal structure of the Deinococcus radiod ...

    The widely conserved natural resistance-associated macrophage protein (Nramp) family of divalent metal transporters enables manganese import in bacteria and dietary iron uptake in mammals. We determined the crystal structure of the Deinococcus radiodurans Nramp homolog (DraNramp) in an inward-facing apo state, including the complete transmembrane (TM) segment 1a (absent from a previous Nramp structure). Mapping our cysteine accessibility scanning results onto this structure, we identified the metal-permeation pathway in the alternate outward-open conformation. We investigated the functional impact of two natural anemia-causing glycine-to-arginine mutations that impaired transition metal transport in both human Nramp2 and DraNramp. The TM4 G153R mutation perturbs the closing of the outward metal-permeation pathway and alters the selectivity of the conserved metal-binding site. In contrast, the TM1a G45R mutation prevents conformational change by sterically blocking the essential movement of that helix, thus locking the transporter in an inward-facing state.


    Organizational Affiliation

    Department of Molecular and Cellular Biology, Harvard University, 52 Oxford Street, Cambridge, MA 02138, USA. Electronic address: gaudet@mcb.harvard.edu.,Beckman Institute for Advanced Science and Technology, University of Illinois at Urbana-Champaign, Urbana, IL 61801, USA.,Beckman Institute for Advanced Science and Technology, University of Illinois at Urbana-Champaign, Urbana, IL 61801, USA; Department of Physics, University of Illinois at Urbana-Champaign, Urbana, IL 61801, USA.,Department of Molecular and Cellular Biology, Harvard University, 52 Oxford Street, Cambridge, MA 02138, USA.,Whitehead Institute for Biomedical Research, Nine Cambridge Center, Cambridge, MA 02142, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Divalent metal cation transporter MntH
A
420Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422)Mutation(s): 7
Gene Names: mntH
Membrane protein
mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Solute Carrier (SLC) Transporter Superfamily
Protein:
NRAMP transition-metal ion transporter in inward facing apo form
Find proteins for Q9RTP8 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / LMG 4051 / NBRC 15346 / NCIMB 9279 / R1 / VKM B-1422))
Go to UniProtKB:  Q9RTP8
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Fab Heavy Chain
H
213N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Fab Light Chain
L
213N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
OS
Query on OS

Download SDF File
Download CCD File
A, H
OSMIUM ION
Os
XQBKHDFIPARBOX-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.941 Å
  • R-Value Free: 0.313
  • R-Value Work: 0.268
  • Space Group: I 2 2 2
  • Diffraction Data DOI:
    10.15785/SBGRID/332 SBGrid
Unit Cell:
Length (Å)Angle (°)
a = 113.131α = 90.00
b = 132.077β = 90.00
c = 220.995γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
March of Dimes FoundationUnited States--
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States9P41GM104601
National Science Foundation (NSF, United States)United StatesNSF-MCA93S028

Revision History

  • Version 1.0: 2016-11-23
    Type: Initial release
  • Version 1.1: 2016-12-21
    Type: Database references
  • Version 1.2: 2017-09-13
    Type: Author supporting evidence
  • Version 1.3: 2019-11-27
    Type: Author supporting evidence
