5JZL

The Structure of Monomeric Ultra Stable Green Fluorescent Protein


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.175

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

A Novel Ultra-Stable, Monomeric Green Fluorescent Protein For Direct Volumetric Imaging of Whole Organs Using CLARITY.

Scott, D.J.Gunn, N.J.Yong, K.J.Wimmer, V.C.Veldhuis, N.A.Challis, L.M.Haidar, M.Petrou, S.Bathgate, R.A.D.Griffin, M.D.W.

(2018) Sci Rep 8: 667-667

  • DOI: 10.1038/s41598-017-18045-y
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Recent advances in thick tissue clearing are enabling high resolution, volumetric fluorescence imaging of complex cellular networks. Fluorescent proteins (FPs) such as GFP, however, can be inactivated by the denaturing chemicals used to remove lipids ...

    Recent advances in thick tissue clearing are enabling high resolution, volumetric fluorescence imaging of complex cellular networks. Fluorescent proteins (FPs) such as GFP, however, can be inactivated by the denaturing chemicals used to remove lipids in some tissue clearing methods. Here, we solved the crystal structure of a recently engineered ultra-stable GFP (usGFP) and propose that the two stabilising mutations, Q69L and N164Y, act to improve hydrophobic packing in the core of the protein and facilitate hydrogen bonding networks at the surface, respectively. usGFP was found to dimerise strongly, which is not desirable for some applications. A point mutation at the dimer interface, F223D, generated monomeric usGFP (muGFP). Neurons in whole mouse brains were virally transduced with either EGFP or muGFP and subjected to Clear Lipid-exchanged Acrylamide-hybridized Rigid Imaging/Immunostaining/In situ hybridization-compatible Tissue-hYdrogel (CLARITY) clearing. muGFP fluorescence was retained after CLARITY whereas EGFP fluorescence was highly attenuated, thus demonstrating muGFP is a novel FP suitable for applications where high fluorescence stability and minimal self-association are required.


    Organizational Affiliation

    Department of Biochemistry and Molecular Biology, University of Melbourne, Parkville, Victoria, 3010, Australia. daniel.scott@florey.edu.au.,IBM Research, Southbank, Victoria, 3006, Australia.,Department of Biochemistry and Molecular Biology, University of Melbourne, Parkville, Victoria, 3010, Australia. mgriffin@unimelb.edu.au.,Bio21 Molecular Science and Biotechnology Institute, University of Melbourne, Parkville, Victoria, 3010, Australia. mgriffin@unimelb.edu.au.,Drug Discovery Biology, Monash Institute of Pharmaceutical Sciences, Monash University, Parkville, Victoria, 3052, Australia.,Department of Biochemistry and Molecular Biology, University of Melbourne, Parkville, Victoria, 3010, Australia.,The Florey Institute of Neuroscience and Mental Health, Parkville, Victoria, 3052, Australia.,The Florey Institute of Neuroscience and Mental Health, Parkville, Victoria, 3052, Australia. daniel.scott@florey.edu.au.,ARC Centre of Excellence in Convergent Bio-Nano Science and Technology, Monash University, Parkville, Victoria, 3052, Australia.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Green fluorescent protein
A, B
249Aequorea victoriaMutation(s): 0
Gene Names: GFP
Find proteins for P42212 (Aequorea victoria)
Go to UniProtKB:  P42212
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
B
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
A, B
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
CRO
Query on CRO
A, B
L-PEPTIDE LINKINGC15 H17 N3 O5THR, TYR, GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.175
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 47.352α = 90.00
b = 95.706β = 104.21
c = 59.649γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
REFMACrefinement
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-12-06
    Type: Initial release
  • Version 1.1: 2018-03-07
    Type: Database references
  • Version 1.2: 2018-12-19
    Type: Data collection, Database references
