5JEJ | pdb_00005jej

Phosphorylated STING in complex with IRF-3 CTD


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:
    0.237 (Depositor), 0.239 (DCC)
  • R-Value Work:
    0.176 (Depositor), 0.180 (DCC)
  • R-Value Observed:
    0.180 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5JEJ

This is version 1.2 of the entry. See complete history

Literature

Structural basis for concerted recruitment and activation of IRF-3 by innate immune adaptor proteins.

Zhao, B.Shu, C.Gao, X.Sankaran, B.Du, F.Shelton, C.L.Herr, A.B.Ji, J.Y.Li, P.

(2016) Proc Natl Acad Sci U S A 113: E3403-E3412

  • DOI: https://doi.org/10.1073/pnas.1603269113
  • Primary Citation Related Structures:
    5JEJ, 5JEK, 5JEL, 5JEM, 5JEO, 5JER

  • PubMed Abstract:

    Type I IFNs are key cytokines mediating innate antiviral immunity. cGMP-AMP synthase, ritinoic acid-inducible protein 1 (RIG-I)-like receptors, and Toll-like receptors recognize microbial double-stranded (ds)DNA, dsRNA, and LPS to induce the expression of type I IFNs. These signaling pathways converge at the recruitment and activation of the transcription factor IRF-3 (IFN regulatory factor 3). The adaptor proteins STING (stimulator of IFN genes), MAVS (mitochondrial antiviral signaling), and TRIF (TIR domain-containing adaptor inducing IFN-β) mediate the recruitment of IRF-3 through a conserved pLxIS motif. Here we show that the pLxIS motif of phosphorylated STING, MAVS, and TRIF binds to IRF-3 in a similar manner, whereas residues upstream of the motif confer specificity. The structure of the IRF-3 phosphomimetic mutant S386/396E bound to the cAMP response element binding protein (CREB)-binding protein reveals that the pLxIS motif also mediates IRF-3 dimerization and activation. Moreover, rotavirus NSP1 (nonstructural protein 1) employs a pLxIS motif to target IRF-3 for degradation, but phosphorylation of NSP1 is not required for its activity. These results suggest a concerted mechanism for the recruitment and activation of IRF-3 that can be subverted by viral proteins to evade innate immune responses.


  • Organizational Affiliation
    • Department of Biochemistry and Biophysics, Texas A&M University, College Station, TX 77843;

Macromolecule Content

  • Total Structure Weight: 66.54 kDa
  • Atom Count: 4,338
  • Modeled Residue Count: 502
  • Deposited Residue Count: 601
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Stimulator of interferon genes proteinA [auth C],
B [auth D],
C [auth E]
39Homo sapiensMutation(s): 0
Gene Names: TMEM173ERISMITASTING
UniProt & NIH Common Fund Data Resources
Find proteins for Q86WV6 (Homo sapiens)
Explore Q86WV6
Go to UniProtKB:  Q86WV6
PHAROS:  Q86WV6
GTEx:  ENSG00000184584
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ86WV6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Interferon regulatory factor 3D [auth A],
E [auth B]
242Homo sapiensMutation(s): 0
Gene Names: IRF3
UniProt & NIH Common Fund Data Resources
Find proteins for Q14653 (Homo sapiens)
Explore Q14653
Go to UniProtKB:  Q14653
PHAROS:  Q14653
GTEx:  ENSG00000126456
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ14653
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
SEP
Query on SEP
A [auth C],
B [auth D],
C [auth E]
L-PEPTIDE LINKINGC3 H8 N O6 PSER

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free:  0.237 (Depositor), 0.239 (DCC)
  • R-Value Work:  0.176 (Depositor), 0.180 (DCC)
  • R-Value Observed: 0.180 (Depositor)
Space Group: P 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.076α = 90
b = 56.401β = 104.64
c = 75.548γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
DENZOdata reduction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Released Date: 2016-06-15
  • Deposition Author(s): Li, P., Shu, C.

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-15
    Type: Initial release
  • Version 1.1: 2016-06-29
    Changes: Database references
  • Version 1.2: 2024-10-09
    Changes: Data collection, Database references, Derived calculations, Structure summary
