5JBW

Crystal structure of LiuC


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free: 0.210
  • R-Value Work: 0.173

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

The Structure of LiuC, a 3-Hydroxy-3-Methylglutaconyl CoA Dehydratase Involved in Isovaleryl-CoA Biosynthesis in Myxococcus xanthus, Reveals Insights into Specificity and Catalysis.

Bock, T.Reichelt, J.Muller, R.Blankenfeldt, W.

(2016) Chembiochem 17: 1658-1664

  • DOI: 10.1002/cbic.201600225
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Myxobacteria are able to produce the important metabolite isovaleryl coenzyme A by a route other than leucine degradation. The first step into this pathway is mediated by LiuC, a member of the 3-methylglutaconyl CoA hydratases (MGCH). Here we present ...

    Myxobacteria are able to produce the important metabolite isovaleryl coenzyme A by a route other than leucine degradation. The first step into this pathway is mediated by LiuC, a member of the 3-methylglutaconyl CoA hydratases (MGCH). Here we present crystal structures refined to 2.05 and 1.1 Å of LiuC in the apo form and bound to coenzyme A, respectively. By using simulated annealing we modeled the enzyme substrate complex and identified residues potentially involved in substrate binding, specificity, and catalysis. The dehydration of 3-hydroxy-3-methylglutaconyl CoA to 3-methylglutaconyl CoA catalyzed by LiuC involves Glu112 and Glu132 and likely employs the typical crotonase acid-base mechanism. In this, Tyr231 and Arg69 are key players in positioning the substrate to enable catalysis. Surprisingly, LiuC shows higher sequence and structural similarity to human MGCH than to bacterial forms, although they convert the same substrate. This study provides structural insights into the alternative isovaleryl coenzyme A biosynthesis pathway and might open a path for biofuel research, as isovaleryl-CoA is a source for isobutene, a precursor for renewable fuels and chemicals.


    Organizational Affiliation

    Structure and Function of Proteins, Helmholtz Centre for Infection Research, Inhoffenstrasse 7, 38124, Braunschweig, Germany.,Institut für Biochemie, Biotechnologie und Bioinformatik, Technische Universität Braunschweig, Spielmannstrasse 7, 38106, Braunschweig, Germany. wulf.blankenfeldt@helmholtz-hzi.de.,Department of Microbial Natural Products, Helmholtz Institute for Pharmaceutical Research Saarland, Centre for Infection Research and Pharmaceutical Biotechnology, Saarland University, Universitätscampus, Gebäude E8 1, 66123, Saarbrücken, Germany.,Structure and Function of Proteins, Helmholtz Centre for Infection Research, Inhoffenstrasse 7, 38124, Braunschweig, Germany. wulf.blankenfeldt@helmholtz-hzi.de.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
3-hydroxybutyryl-CoA dehydratase
A
260Myxococcus xanthus (strain DK 1622)Mutation(s): 0
Gene Names: crt
EC: 4.2.1.55
Find proteins for Q1D5Y4 (Myxococcus xanthus (strain DK 1622))
Go to UniProtKB:  Q1D5Y4
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.05 Å
  • R-Value Free: 0.210
  • R-Value Work: 0.173
  • Space Group: P 21 3
Unit Cell:
Length (Å)Angle (°)
a = 115.790α = 90.00
b = 115.790β = 90.00
c = 115.790γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
PHENIXrefinement
Aimlessdata scaling
PDB_EXTRACTdata extraction
PHENIXphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2016-06-22
    Type: Initial release
  • Version 1.1: 2016-09-14
    Type: Database references
