Biological Assembly 1

 3D View: Structure | Electron Density

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 60.98 kDa
• Atom Count: 4453
• Modelled Residue Count: 507
• Deposited Residue Count: 534
• Unique protein chains: 1

5I62

Crystal structure of the insertion loop deletion mutant of the RNA-dependent RNA polymerase of a human picorbirnavirus

• DOI: 10.2210/pdb5I62/pdb

• Classification: viral protein, replication
• Organism(s): Human picobirnavirus strain Hy005102
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2016-02-15 Released: 2016-03-16
• Deposition Author(s): Collier, A.M., Guo, Y.R., Tao, Y.J.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.201
• R-Value Work: 0.172
• R-Value Observed: 0.173

Literature

Initiation of RNA Polymerization and Polymerase Encapsidation by a Small dsRNA Virus.

Collier, A.M., Lyytinen, O.L., Guo, Y.R., Toh, Y., Poranen, M.M., Tao, Y.J.

(2016) PLoS Pathog 12: e1005523-e1005523

• PubMed: 27078841
• DOI: 10.1371/journal.ppat.1005523
• Primary Citation of Related Structures:
  5I61, 5I62


• PubMed Abstract:


During the replication cycle of double-stranded (ds) RNA viruses, the viral RNA-dependent RNA polymerase (RdRP) replicates and transcribes the viral genome from within the viral capsid. How the RdRP molecules are packaged within the virion and how they function within the confines of an intact capsid are intriguing questions with answers that most likely vary across the different dsRNA virus families. In this study, we have determined a 2.4 Å resolution structure of an RdRP from the human picobirnavirus (hPBV). In addition to the conserved polymerase fold, the hPBV RdRP possesses a highly flexible 24 amino acid loop structure located near the C-terminus of the protein that is inserted into its active site. In vitro RNA polymerization assays and site-directed mutagenesis showed that: (1) the hPBV RdRP is fully active using both ssRNA and dsRNA templates; (2) the insertion loop likely functions as an assembly platform for the priming nucleotide to allow de novo initiation; (3) RNA transcription by the hPBV RdRP proceeds in a semi-conservative manner; and (4) the preference of virus-specific RNA during transcription is dictated by the lower melting temperature associated with the terminal sequences. Co-expression of the hPBV RdRP and the capsid protein (CP) indicated that, under the conditions used, the RdRP could not be incorporated into the recombinant capsids in the absence of the viral genome. Additionally, the hPBV RdRP exhibited higher affinity towards the conserved 5'-terminal sequence of the viral RNA, suggesting that the RdRP molecules may be encapsidated through their specific binding to the viral RNAs during assembly.

---

Organizational Affiliation:

Department of BioSciences, Rice University, Houston, Texas, United States of America.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Potential RNA-dependent RNA polymerase	A	534	Human picobirnavirus strain Hy005102	Mutation(s): 0  Gene Names: Segment-2, ORF3 EC: 2.7.7.48
UniProt
Find proteins for Q50LE4 (Human picobirnavirus (strain Human/Thailand/Hy005102/-)) Explore Q50LE4  Go to UniProtKB:  Q50LE4

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.201
• R-Value Work: 0.172
• R-Value Observed: 0.173
• Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 77.534	α = 90
b = 77.534	β = 90
c = 183.858	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data scaling
PDB_EXTRACT	data extraction
HKL-2000	data reduction
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2016-02-15
• Released Date: 2016-03-16
Deposition Author(s): Collier, A.M., Guo, Y.R., Tao, Y.J.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	AIO67638

Revision History

• Version 1.0: 2016-03-16
  Type: Initial release

• Version 1.1: 2016-05-04
  Changes: Database references, Structure summary
• Version 1.2: 2017-09-20
  Changes: Author supporting evidence, Derived calculations
• Version 1.3: 2019-12-11
  Changes: Author supporting evidence
