5HX8

Jak1 complex with 4-[(4-aminocyclohexyl)amino]-3-(1H-benzimidazol-2-yl)-1H-pyridin-2-one


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.197
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structure-based design and development of (benz)imidazole pyridones as JAK1-selective kinase inhibitors.

Simov, V.Deshmukh, S.V.Dinsmore, C.J.Elwood, F.Fernandez, R.B.Garcia, Y.Gibeau, C.Gunaydin, H.Jung, J.Katz, J.D.Kraybill, B.Lapointe, B.Patel, S.B.Siu, T.Su, H.Young, J.R.

(2016) Bioorg Med Chem Lett 26: 1803-1808

  • DOI: https://doi.org/10.1016/j.bmcl.2016.02.035
  • Primary Citation of Related Structures:
    5HX8

  • PubMed Abstract:

    The mammalian Janus Kinases (JAK1, JAK2, JAK3 and TYK2) are intracellular, non-receptor tyrosine kinases whose activities have been associated in the literature and the clinic with a variety of hyperproliferative diseases and immunological disorders. At the onset of the program, it was hypothesized that a JAK1 selective compound over JAK2 could lead to an improved therapeutic index relative to marketed non-selective JAK inhibitors by avoiding the clinical AEs, such as anemia, presumably associated with JAK2 inhibition. During the course of the JAK1 program, a number of diverse chemical scaffolds were identified from both uHTS campaigns and de novo scaffold design. As part of this effort, a (benz)imidazole scaffold evolved via a scaffold-hopping exercise from a mature chemical series. Concurrent crystallography-driven exploration of the ribose pocket and the solvent front led to analogs with optimized kinome and JAK1 selectivities over the JAK2 isoform by targeting several residues unique to JAK1, such as Arg-879 and Glu-966.


  • Organizational Affiliation

    Merck & Co., 33 Avenue Louis Pasteur, Boston, MA, United States. Electronic address: vladimir_simov@merck.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tyrosine-protein kinase JAK1
A, B
302Homo sapiensMutation(s): 0
Gene Names: JAK1JAK1AJAK1B
EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for P23458 (Homo sapiens)
Explore P23458
Go to UniProtKB:  P23458
PHAROS:  P23458
GTEx:  ENSG00000162434
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP23458
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
66P
Query on 66P

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
4-[(4-aminocyclohexyl)amino]-3-(1H-benzimidazol-2-yl)-1H-pyridin-2-one
C18 H21 N5 O
JLWGOAGEDWMEBT-TXEJJXNPSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
PTR
Query on PTR
A, B
L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Binding Affinity Annotations
IDSourceBinding Affinity
66P BindingDB:  5HX8 IC50: min: 0.1, max: 3 (nM) from 2 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.197
  • R-Value Observed: 0.199
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.76α = 90
b = 172.97β = 93.6
c = 44.72γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
BUSTER-TNTrefinement
PDB_EXTRACTdata extraction
BUSTERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

  • Released Date: 2016-03-16
  • Deposition Author(s): Su, H.P.

Revision History  (Full details and data files)

  • Version 1.0: 2016-03-16
    Type: Initial release
  • Version 1.1: 2016-03-23
    Changes: Database references
  • Version 1.2: 2017-11-22
    Changes: Database references, Derived calculations, Refinement description
