5FEI

Crystal structure of the bacteriophage phi29 tail knob protein gp9 truncation variant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.201
  • R-Value Work: 0.166
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

The bacteriophage 29 tail possesses a pore-forming loop for cell membrane penetration.

Xu, J.Gui, M.Wang, D.Xiang, Y.

(2016) Nature 534: 544-547

  • DOI: https://doi.org/10.1038/nature18017
  • Primary Citation of Related Structures:
    5FB4, 5FB5, 5FEI

  • PubMed Abstract:

    Most bacteriophages are tailed bacteriophages with an isometric or a prolate head attached to a long contractile, long non-contractile, or short non-contractile tail. The tail is a complex machine that plays a central role in host cell recognition and attachment, cell wall and membrane penetration, and viral genome ejection. The mechanisms involved in the penetration of the inner host cell membrane by bacteriophage tails are not well understood. Here we describe structural and functional studies of the bacteriophage ϕ29 tail knob protein gene product 9 (gp9). The 2.0 Å crystal structure of gp9 shows that six gp9 molecules form a hexameric tube structure with six flexible hydrophobic loops blocking one end of the tube before DNA ejection. Sequence and structural analyses suggest that the loops in the tube could be membrane active. Further biochemical assays and electron microscopy structural analyses show that the six hydrophobic loops in the tube exit upon DNA ejection and form a channel that spans the lipid bilayer of the membrane and allows the release of the bacteriophage genomic DNA, suggesting that cell membrane penetration involves a pore-forming mechanism similar to that of certain non-enveloped eukaryotic viruses. A search of other phage tail proteins identified similar hydrophobic loops, which indicates that a common mechanism might be used for membrane penetration by prokaryotic viruses. These findings suggest that although prokaryotic and eukaryotic viruses use apparently very different mechanisms for infection, they have evolved similar mechanisms for breaching the cell membrane.


  • Organizational Affiliation

    Centre for Infectious Diseases Research, Collaborative Innovation Center for Diagnosis and Treatment of Infectious Diseases, Beijing Advanced Innovation Center for Structural Biology, Department of Basic Medical Sciences, School of Medicine, Tsinghua University, Beijing 100084, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Distal tube protein
A, B
605Salasvirus phi29Mutation(s): 0
UniProt
Find proteins for P04331 (Bacillus phage phi29)
Explore P04331
Go to UniProtKB:  P04331
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04331
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.201
  • R-Value Work: 0.166
  • R-Value Observed: 0.168
  • Space Group: P 21 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 184.671α = 90
b = 184.671β = 90
c = 184.671γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data collection
HKL-2000data scaling
SHARPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
973 programChina2015CB13910102
the National Natural Science Foundation of ChinaChina31470721
the National Natural Science Foundation of ChinaChina81550001
the Junior Thousand Talents Program of ChinaChina20131770418

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-22
    Type: Initial release
  • Version 1.1: 2016-06-29
    Changes: Database references
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references, Derived calculations
