5ELG | pdb_00005elg

The structure of DHAR1 from Arabidopsis thaliana

PDB DOI: https://doi.org/10.2210/pdb5ELG/pdb

Classification: TRANSFERASE
Organism(s): Arabidopsis thaliana
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2015-11-04 Released: 2016-11-16
Deposition Author(s): Menault, M., Roszak, A.W., Lapthorn, A.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.81 Å
R-Value Free:
0.195 (Depositor), 0.210 (DCC)
R-Value Work:
0.161 (Depositor), 0.174 (DCC)
R-Value Observed:
0.163 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5ELG

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Arabidopsis thaliana DHAR1 apo structure

Menault, M., Roszak, A.W., Lapthorn, A.J.

To be published.

Macromolecule Content

Total Structure Weight: 25.5 kDa
Atom Count: 1,967
Modeled Residue Count: 212
Deposited Residue Count: 221
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutathione S-transferase DHAR1, mitochondrial	A	221	Arabidopsis thaliana	Mutation(s): 0 Gene Names: DHAR1, DHAR5, At1g19570, F14P1.9, F18O14.22 EC: 2.5.1.18 (PDB Primary Data), 1.8.5.1 (UniProt)
UniProt
Find proteins for Q9FWR4 (Arabidopsis thaliana) Explore Q9FWR4 Go to UniProtKB: Q9FWR4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9FWR4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GSH Query on GSH Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	Glutathione C₁₀ H₁₇ N₃ O₆ S RWSXRVCMGQZWBV-WDSKDSINSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain B [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain B [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain B [auth A]	B [auth A], D [auth A], E [auth A], F [auth A], G [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain B [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]

Biologically Interesting Molecules (External Reference)

1 Unique

Entity ID: 3
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_002593 (GSH) Query on PRD_002593	C [auth A]	Glutathione	Peptide-like / Oxidation-reduction		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.81 Å
R-Value Free: 0.195 (Depositor), 0.210 (DCC)
R-Value Work: 0.161 (Depositor), 0.174 (DCC)
R-Value Observed: 0.163 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.92	α = 90
b = 63.92	β = 90
c = 266.26	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2016-11-16

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2016-11-16
Type: Initial release
Version 1.1: 2024-05-08
Changes: Data collection, Database references
