5EHU

sfGFP mutant with unnatural amino acid 4-azidoethoxy-L-phenylalanine incorporated at the 149 site

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.45 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.175
  • R-Value Observed: 0.176

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history.


Literature

Azidoethoxyphenylalanine as a Vibrational Reporter and Click Chemistry Partner in Proteins.

Tookmanian, E.M., Phillips-Piro, C.M., Fenlon, E.E., Brewer, S.H.

(2015) Chemistry 21: 19096-19103

  • DOI: 10.1002/chem.201503908
  • Primary Citation of Related Structures:
    5EHU

  • PubMed Abstract:

    • An unnatural amino acid, 4-(2-azidoethoxy)-L-phenylalanine (AePhe, 1), was designed and synthesized in three steps from known compounds in 54% overall yield. The sensitivity of the IR absorption of the azide of AePhe was established by comparison of ...

    An unnatural amino acid, 4-(2-azidoethoxy)-L-phenylalanine (AePhe, 1), was designed and synthesized in three steps from known compounds in 54% overall yield. The sensitivity of the IR absorption of the azide of AePhe was established by comparison of the frequency of the azide asymmetric stretch vibration in water and dimethyl sulfoxide. AePhe was successfully incorporated into superfolder green fluorescent protein (sfGFP) at the 133 and 149 sites by using the amber codon suppression method. The IR spectra of these sfGFP constructs indicated that the azide group at the 149 site was not fully solvated despite the location in sfGFP and the three-atom linker between the azido group and the aromatic ring of AePhe. An X-ray crystal structure of sfGFP-149-AePhe was solved at 1.45 Å resolution and provides an explanation for the IR data as the flexible linker adopts a conformation which partially buries the azide on the protein surface. Both sfGFP-AePhe constructs efficiently undergo a bioorthogonal strain-promoted click cycloaddition with a dibenzocyclooctyne derivative.

    Organizational Affiliation:

    Department of Chemistry Franklin & Marshall College, P.O. Box 3003, Lancaster, PA 17604 (USA). sbrewer@fandm.edu.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Green fluorescent proteinA, B237Aequorea victoriaMutation(s): 7
Gene Names: GFP
Find proteins for P42212 (Aequorea victoria)
Explore P42212
Go to UniProtKB:  P42212
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  2 Unique
IDChainsTypeFormula2D DiagramParent
4LZ
Query on 4LZ		A,BL-PEPTIDE LINKINGC11 H15 N4 O3TYR
CRO
Query on CRO		A,BL-PEPTIDE LINKINGC15 H17 N3 O5THR, TYR, GLY
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.45 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.175
  • R-Value Observed: 0.176
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 129.917α = 90
b = 37.492β = 106.31
c = 91.848γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report


View more in-depth experimental data

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR15GM093330-02
National Science Foundation (NSF, United States)United StatesCHE-1053946

Revision History

  • Version 1.0: 2015-12-23
    Type: Initial release
  • Version 1.1: 2016-01-27
    Changes: Database references
  • Version 1.2: 2017-09-27
    Changes: Author supporting evidence, Derived calculations
  • Version 1.3: 2019-11-27
    Changes: Author supporting evidence
