5EGQ

Structure of tetrameric rat phenylalanine hydroxylase mutant R270K, residues 25-453


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.256
  • R-Value Work: 0.211

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Domain Movements upon Activation of Phenylalanine Hydroxylase Characterized by Crystallography and Chromatography-Coupled Small-Angle X-ray Scattering.

Meisburger, S.P.Taylor, A.B.Khan, C.A.Zhang, S.Fitzpatrick, P.F.Ando, N.

(2016) J.Am.Chem.Soc. 138: 6506-6516

  • DOI: 10.1021/jacs.6b01563
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Mammalian phenylalanine hydroxylase (PheH) is an allosteric enzyme that catalyzes the first step in the catabolism of the amino acid phenylalanine. Following allosteric activation by high phenylalanine levels, the enzyme catalyzes the pterin-dependen ...

    Mammalian phenylalanine hydroxylase (PheH) is an allosteric enzyme that catalyzes the first step in the catabolism of the amino acid phenylalanine. Following allosteric activation by high phenylalanine levels, the enzyme catalyzes the pterin-dependent conversion of phenylalanine to tyrosine. Inability to control elevated phenylalanine levels in the blood leads to increased risk of mental disabilities commonly associated with the inherited metabolic disorder, phenylketonuria. Although extensively studied, structural changes associated with allosteric activation in mammalian PheH have been elusive. Here, we examine the complex allosteric mechanisms of rat PheH using X-ray crystallography, isothermal titration calorimetry (ITC), and small-angle X-ray scattering (SAXS). We describe crystal structures of the preactivated state of the PheH tetramer depicting the regulatory domains docked against the catalytic domains and preventing substrate binding. Using SAXS, we further describe the domain movements involved in allosteric activation of PheH in solution and present the first demonstration of chromatography-coupled SAXS with Evolving Factor Analysis (EFA), a powerful method for separating scattering components in a model-independent way. Together, these results support a model for allostery in PheH in which phenylalanine stabilizes the dimerization of the regulatory domains and exposes the active site for substrate binding and other structural changes needed for activity.


    Organizational Affiliation

    Department of Chemistry, Princeton University , Princeton, New Jersey 08544, United States.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Phenylalanine-4-hydroxylase
A, B, C, D
453Rattus norvegicusMutation(s): 1
Gene Names: Pah
EC: 1.14.16.1
Find proteins for P04176 (Rattus norvegicus)
Go to UniProtKB:  P04176
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, C, D
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.5 Å
  • R-Value Free: 0.256
  • R-Value Work: 0.211
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 90.144α = 90.00
b = 96.507β = 90.00
c = 202.584γ = 90.00
Software Package:
Software NamePurpose
XDSdata scaling
PHASERphasing
XDSdata reduction
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2016-05-18
    Type: Initial release
  • Version 1.1: 2016-06-08
    Type: Database references
