5B5J

Hen egg white lysozyme with boron tracedrug UTX-97


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.26 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.193

wwPDB Validation 3D Report Full Report


This is version 1.0 of the entry. See complete history

Literature

Structural Insight Into Protein Binding of Boron Tracedrug UTX-97 Revealed by the Co-Crystal Structure With Lysozyme at 1.26 angstrom Resolution.

Morimoto, Y.Nagasawa, H.Uto, Y.Chatake, T.Hori, H.

(2016) J Pharm Sci 105: 2298-2301

  • DOI: 10.1016/j.xphs.2016.06.005

  • PubMed Abstract:
  • Boron neutron capture therapy (BNCT) is one of the numbers of radiotherapies for treatment of certain cancers. The ability of low-dose irradiation with neutrons or radioactive beams to provide an acceptable quality of life is an objective which has n ...

    Boron neutron capture therapy (BNCT) is one of the numbers of radiotherapies for treatment of certain cancers. The ability of low-dose irradiation with neutrons or radioactive beams to provide an acceptable quality of life is an objective which has not yet been achieved; therefore it will be necessary to increase the efficiency of the neutron capture reaction by lower dose irradiation and by achieving higher drug concentrations in living cells. Drug selectivity in targeting the affected cellular compartment is most important. Molecular design and synthesis of drugs should be based on high resolution structures and analysis of specific compounds and host molecules; however, it is necessary to obtain crystals for X-ray structural analysis. Because compounds containing bulky functional groups are difficult to crystalize due to their flexibility, the method described here makes it possible to stabilize these compounds by complexing them with protein molecules. We have first solved the three-dimensional structure of a BNCT drug-protein molecule combination at 1.26 Å resolution, and discuss the nature of the interaction between a BNCT drug and the protein molecule residues.


    Organizational Affiliation

    Research Reactor Institute, Kyoto University, Kumatori, Osaka 590-0494, Japan. Electronic address: morimoto@rri.kyoto-u.ac.jp.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Lysozyme C
A
129Gallus gallusMutation(s): 0
Gene Names: LYZ
EC: 3.2.1.17
Find proteins for P00698 (Gallus gallus)
Go to Gene View: LYZ
Go to UniProtKB:  P00698
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NA
Query on NA

Download SDF File
Download CCD File
A
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
UTX
Query on UTX

Download SDF File
Download CCD File
A
2-cyano-3-((6-(((2-((2-cyanoethyl)(borocaptate-10B)sulfonio)acetyl)carbamoyl)oxy)hexyl)amino)quinoxaline 1,4-dioxide
UTX-97
C21 H29 B12 N6 O5 S
XGCBKBJDCVTBSO-QUCCMNQESA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.26 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.193
  • Space Group: P 43 21 2
Unit Cell:
Length (Å)Angle (°)
a = 78.440α = 90.00
b = 78.440β = 90.00
c = 37.353γ = 90.00
Software Package:
Software NamePurpose
MOLREPphasing
SCALEPACKdata scaling
REFMACrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

  • Deposited Date: 2016-05-11
  • Released Date: 2017-06-28
  • Deposition Author(s): Morimoto, Y.

Revision History

  • Version 1.0: 2017-06-28
    Type: Initial release
