5B19 | pdb_00005b19

Picrophilus torridus aspartate racemase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free:
    0.269 (Depositor), 0.269 (DCC)
  • R-Value Work:
    0.239 (Depositor), 0.241 (DCC)
  • R-Value Observed:
    0.240 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5B19

This is version 1.3 of the entry. See complete history

Literature

Structural and functional characterization of aspartate racemase from the acidothermophilic archaeon Picrophilus torridus

Aihara, T.Ito, T.Yamanaka, Y.Noguchi, K.Odaka, M.Sekine, M.Homma, H.Yohda, M.

(2016) Extremophiles 20: 385-393

  • DOI: https://doi.org/10.1007/s00792-016-0829-7
  • Primary Citation Related Structures:
    5B19

  • PubMed Abstract:

    Functional and structural characterizations of pyridoxal 5'-phosphate-independent aspartate racemase of the acidothermophilic archaeon Picrophilus torridus were performed. Picrophilus aspartate racemase exhibited high substrate specificity to aspartic acid. The optimal reaction temperature was 60 °C, which is almost the same as the optimal growth temperature. Reflecting the low pH in the cytosol, the optimal reaction pH of Picrophilus aspartate racemase was approximately 5.5. However, the activity at the putative cytosolic pH of 4.6 was approximately 6 times lower than that at the optimal pH of 5.5. The crystal structure of Picrophilus aspartate racemase was almost the same as that of other pyridoxal 5'-phosphate -independent aspartate racemases. In two molecules of the dimer, one molecule contained a tartaric acid molecule in the catalytic site; the structure of the other molecule was relatively flexible. Finally, we examined the intracellular existence of D-amino acids. Unexpectedly, the proportion of D-aspartate to total aspartate was not very high. In contrast, both D-proline and D-alanine were observed. Because Picrophilus aspartate racemase is highly specific to aspartate, other amino acid racemases might exist in Picrophilus torridus.


  • Organizational Affiliation
    • Department of Biotechnology and Life Science, Graduate School of Technology, Tokyo University of Agriculture and Technology, 2-24-16 Naka-cho, Koganei, Tokyo, 184-8588, Japan.

Macromolecule Content

  • Total Structure Weight: 52.07 kDa
  • Atom Count: 3,044
  • Modeled Residue Count: 378
  • Deposited Residue Count: 464
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Aspartate racemase
A, B
232Picrophilus oshimae DSM 9789Mutation(s): 0
Gene Names: PTO0149
EC: 5.1.1.13
UniProt
Find proteins for Q6L2R8 (Picrophilus torridus (strain ATCC 700027 / DSM 9790 / JCM 10055 / NBRC 100828 / KAW 2/3))
Explore Q6L2R8
Go to UniProtKB:  Q6L2R8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6L2R8
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TLA

Query on TLA



Download:Ideal Coordinates CCD File
C [auth A]L(+)-TARTARIC ACID
C4 H6 O6
FEWJPZIEWOKRBE-JCYAYHJZSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.85 Å
  • R-Value Free:  0.269 (Depositor), 0.269 (DCC)
  • R-Value Work:  0.239 (Depositor), 0.241 (DCC)
  • R-Value Observed: 0.240 (Depositor)
Space Group: P 21 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 111.506α = 90
b = 111.506β = 90
c = 111.506γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-22
    Type: Initial release
  • Version 1.1: 2016-07-13
    Changes: Database references
  • Version 1.2: 2020-02-26
    Changes: Data collection, Derived calculations
  • Version 1.3: 2023-11-08
    Changes: Data collection, Database references, Refinement description
