4ZCK

Crystal Structure of C-terminal Fragment of Escherichia coli BipA/TypA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.194
  • R-Value Observed: 0.196

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structural and Functional Analysis of BipA, a Regulator of Virulence in Enteropathogenic Escherichia coli.

Fan, H.Hahm, J.Diggs, S.Perry, J.J.Blaha, G.

(2015) J Biol Chem 290: 20856-20864

  • DOI: 10.1074/jbc.M115.659136
  • Primary Citation of Related Structures:
    4ZCM, 4ZCI, 4ZCK, 4ZCL

  • PubMed Abstract:
  • The translational GTPase BipA regulates the expression of virulence and pathogenicity factors in several eubacteria. BipA-dependent expression of virulence factors occurs under starvation conditions, such as encountered during infection of a host. Under these conditions, BipA associates with the small ribosomal subunit ...

    The translational GTPase BipA regulates the expression of virulence and pathogenicity factors in several eubacteria. BipA-dependent expression of virulence factors occurs under starvation conditions, such as encountered during infection of a host. Under these conditions, BipA associates with the small ribosomal subunit. BipA also has a second function to promote the efficiency of late steps in biogenesis of large ribosomal subunits at low temperatures, presumably while bound to the ribosome. During starvation, the cellular concentration of stress alarmone guanosine-3', 5'-bis pyrophosphate (ppGpp) is increased. This increase allows ppGpp to bind to BipA and switch its binding specificity from ribosomes to small ribosomal subunits. A conformational change of BipA upon ppGpp binding could explain the ppGpp regulation of the binding specificity of BipA. Here, we present the structures of the full-length BipA from Escherichia coli in apo, GDP-, and ppGpp-bound forms. The crystal structure and small-angle x-ray scattering data of the protein with bound nucleotides, together with a thermodynamic analysis of the binding of GDP and of ppGpp to BipA, indicate that the ppGpp-bound form of BipA adopts the structure of the GDP form. This suggests furthermore, that the switch in binding preference only occurs when both ppGpp and the small ribosomal subunit are present. This molecular mechanism would allow BipA to interact with both the ribosome and the small ribosomal subunit during stress response.


    Organizational Affiliation

    From the Department of Biochemistry, University of California, Riverside, California 92521 gregor.blaha@ucr.edu.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
GTP-binding protein TypA/BipAA332Escherichia coli K-12Mutation(s): 0
Gene Names: typAbipAyihKb3871JW5571
EC: 3.6.5
Find proteins for P0A3B2 (Escherichia coli O127:H6 (strain E2348/69 / EPEC))
Explore P0A3B2
Go to UniProtKB:  P0A3B2
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download Ideal Coordinates CCD File
B [auth A], C [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.48 Å
  • R-Value Free: 0.227
  • R-Value Work: 0.194
  • R-Value Observed: 0.196
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 83.562α = 90
b = 83.562β = 90
c = 191.841γ = 90
Software Package:
Software NamePurpose
MOSFLMdata reduction
PHASERphasing
Cootmodel building
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-07-29
    Type: Initial release
  • Version 1.1: 2015-08-05
    Changes: Database references
  • Version 1.2: 2015-09-02
    Changes: Database references
