YcaO with AMP Bound

Experimental Data Snapshot

  • Resolution: 2.25 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.218
  • R-Value Observed: 0.219

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Discovery of a new ATP-binding motif involved in peptidic azoline biosynthesis.

Dunbar, K.L.Chekan, J.R.Cox, C.L.Burkhart, B.J.Nair, S.K.Mitchell, D.A.

(2014) Nat Chem Biol 10: 823-829

  • DOI: https://doi.org/10.1038/nchembio.1608
  • Primary Citation of Related Structures:
    4Q84, 4Q85, 4Q86

  • PubMed Abstract:

    Despite intensive research, the cyclodehydratase responsible for azoline biogenesis in thiazole/oxazole-modified microcin (TOMM) natural products remains enigmatic. The collaboration of two proteins, C and D, is required for cyclodehydration. The C protein is homologous to E1 ubiquitin-activating enzymes, whereas the D protein is within the YcaO superfamily. Recent studies have demonstrated that TOMM YcaOs phosphorylate amide carbonyl oxygens to facilitate azoline formation. Here we report the X-ray crystal structure of an uncharacterized YcaO from Escherichia coli (Ec-YcaO). Ec-YcaO harbors an unprecedented fold and ATP-binding motif. This motif is conserved among TOMM YcaOs and is required for cyclodehydration. Furthermore, we demonstrate that the C protein regulates substrate binding and catalysis and that the proline-rich C terminus of the D protein is involved in C protein recognition and catalysis. This study identifies the YcaO active site and paves the way for the characterization of the numerous YcaO domains not associated with TOMM biosynthesis.

  • Organizational Affiliation

    1] Institute for Genomic Biology, University of Illinois at Urbana-Champaign, Urbana, Illinois, USA. [2] Department of Microbiology, University of Illinois at Urbana-Champaign, Urbana, Illinois, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ribosomal protein S12 methylthiotransferase accessory factor YcaO
A, B, C, D, E
A, B, C, D, E, F, G, H
586Escherichia coli K-12Mutation(s): 0
Gene Names: ycaOb0905JW0888
Find proteins for P75838 (Escherichia coli (strain K12))
Explore P75838
Go to UniProtKB:  P75838
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP75838
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on AMP

Download Ideal Coordinates CCD File
CA [auth G]
GA [auth H]
I [auth A]
M [auth B]
Q [auth C]
CA [auth G],
GA [auth H],
I [auth A],
M [auth B],
Q [auth C],
U [auth D],
Y [auth E]
C10 H14 N5 O7 P
Query on MG

Download Ideal Coordinates CCD File
AA [auth E]
BA [auth E]
DA [auth G]
EA [auth G]
FA [auth G]
AA [auth E],
BA [auth E],
DA [auth G],
EA [auth G],
FA [auth G],
HA [auth H],
IA [auth H],
J [auth A],
JA [auth H],
K [auth A],
L [auth A],
N [auth B],
O [auth B],
P [auth B],
R [auth C],
S [auth C],
T [auth C],
V [auth D],
W [auth D],
X [auth D],
Z [auth E]
Experimental Data & Validation

Experimental Data

  • Resolution: 2.25 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.218
  • R-Value Observed: 0.219
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 111.254α = 89.94
b = 112.949β = 73.51
c = 132.886γ = 77.23
Software Package:
Software NamePurpose
HKL-2000data collection
AutoPROCdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-08-13
    Type: Initial release
  • Version 1.1: 2014-09-03
    Changes: Database references
  • Version 1.2: 2014-10-01
    Changes: Database references
