4F4A

Crystal structure of Nucleoside diphosphate kinase B from Trypanosoma brucei, UDP-bound form

• PDB DOI: https://doi.org/10.2210/pdb4F4A/pdb

• Classification: TRANSFERASE
• Organism(s): Trypanosoma brucei brucei TREU927
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2012-05-10 Released: 2012-05-30
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.195
• R-Value Work: 0.158
• R-Value Observed: 0.160

Literature

Crystal structure of Nucleoside diphosphate kinase B from Trypanosoma brucei, UDP-bound form

Seattle Structural Genomics Center for Infectious Disease (SSGCID), Gardberg, A.S., Edwards, T.E., Staker, B., Stewart, L.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D3  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 52.82 kDa
• Atom Count: 3,999
• Modelled Residue Count: 452
• Deposited Residue Count: 471
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nucleoside diphosphate kinase	A, B, C	157	Trypanosoma brucei brucei TREU927	Mutation(s): 0  Gene Names: Tb11.01.7800 EC: 2.7.4.6
UniProt
Find proteins for Q381H3 (Trypanosoma brucei brucei (strain 927/4 GUTat10.1)) Explore Q381H3  Go to UniProtKB:  Q381H3

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
UDP	D [auth A], F [auth B], H [auth C]	URIDINE-5'-DIPHOSPHATE C9 H14 N2 O12 P2 XCCTYIAWTASOJW-XVFCMESISA-N
MG	E [auth A], G [auth B], I [auth C]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.195
• R-Value Work: 0.158
• R-Value Observed: 0.160
• Space Group: C 2 2 2₁
• Diffraction Data: https://doi.org/10.18430/M34F4A

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 71.83	α = 90
b = 121.51	β = 90
c = 113.17	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2012-05-30
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2012-05-30
  Type: Initial release

• Version 1.1: 2024-02-28
  Changes: Data collection, Database references, Derived calculations
