4E9J

Crystal structure of the N-terminal domain of the secretin XcpQ from Pseudomonas aeruginosa


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.03 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.210
  • R-Value Observed: 0.212

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

New Insights into the Assembly of Bacterial Secretins: STRUCTURAL STUDIES OF THE PERIPLASMIC DOMAIN OF XcpQ FROM PSEUDOMONAS AERUGINOSA.

Van der Meeren, R.Wen, Y.Van Gelder, P.Tommassen, J.Devreese, B.Savvides, S.N.

(2013) J Biol Chem 288: 1214-1225

  • DOI: 10.1074/jbc.M112.432096
  • Primary Citation of Related Structures:
    4E9J, 4EC5

  • PubMed Abstract:
  • The type II secretion system is a multiprotein assembly spanning the inner and outer membranes in Gram-negative bacteria. It is found in almost all pathogenic bacteria where it contributes to virulence, host tissue colonization, and infection. The ex ...

    The type II secretion system is a multiprotein assembly spanning the inner and outer membranes in Gram-negative bacteria. It is found in almost all pathogenic bacteria where it contributes to virulence, host tissue colonization, and infection. The exoproteins are secreted across the outer membrane via a large translocation channel, the secretin, which typically adopts a dodecameric structure. These secretin channels have large periplasmic N-terminal domains that reach out into the periplasm for communication with the inner membrane platform and with a pseudopilus structure that spans the periplasm. Here we report the crystal structure of the N-terminal periplasmic domain of the secretin XcpQ from Pseudomonas aeruginosa, revealing a two-lobe dimeric assembly featuring parallel subunits engaging in well defined interactions at the tips of each lobe. We have employed structure-based engineering of disulfide bridges and native mass spectrometry to show that the periplasmic domain of XcpQ dimerizes in a concentration-dependent manner. Validation of these insights in the context of cellular full-length XcpQ and further evaluation of the functionality of disulfide-linked XcpQ establishes that the basic oligomerization unit of XcpQ is a dimer. This is consistent with the notion that the dodecameric secretin assembles as a hexamer of dimers to ensure correct projection of the N-terminal domains into the periplasm. Therefore, our studies provide a key conceptual advancement in understanding the assembly principles and dynamic function of type II secretion system secretins and challenge recent studies reporting monomers as the basic subunit of the secretin oligomer.


    Organizational Affiliation

    Unit for Structural Biology, Ghent University, 9000 Ghent, Belgium.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
General secretion pathway protein DAB246Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: xcpQPA3105
Find proteins for P35818 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore P35818
Go to UniProtKB:  P35818
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download CCD File
B
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.03 Å
  • R-Value Free: 0.249
  • R-Value Work: 0.210
  • R-Value Observed: 0.212
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 119.5α = 90
b = 39.72β = 99.84
c = 93.3γ = 90
Software Package:
Software NamePurpose
Proximadata collection
PHASERphasing
PHENIXrefinement
XDSdata reduction
AutoPROCdata scaling
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2012-03-21
  • Released Date: 2012-12-05
  • Deposition Author(s): Van der Meeren, R.

Revision History

  • Version 1.0: 2012-12-05
    Type: Initial release
  • Version 1.1: 2013-01-02
    Changes: Database references
  • Version 1.2: 2013-01-16
    Changes: Database references
  • Version 1.3: 2013-02-06
    Changes: Database references
