4ZXG

Ligandin binding site of PfGST


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.183

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

High resolution structures of Plasmodium falciparum GST complexes provide novel insights into the dimer-tetramer transition and a novel ligand-binding site.

Perbandt, M.Eberle, R.Fischer-Riepe, L.Cang, H.Liebau, E.Betzel, C.

(2015) J.Struct.Biol. 191: 365-375

  • DOI: 10.1016/j.jsb.2015.06.008

  • PubMed Abstract:
  • Protection from oxidative stress and efficient redox regulation are essential for malarial parasites which have to grow and multiply rapidly in pro-oxidant rich environments. Therefore, redox active proteins currently belong to the most attractive an ...

    Protection from oxidative stress and efficient redox regulation are essential for malarial parasites which have to grow and multiply rapidly in pro-oxidant rich environments. Therefore, redox active proteins currently belong to the most attractive antimalarial drug targets. The glutathione S-transferase from Plasmodium falciparum (PfGST) is a redox active protein displaying a peculiar dimer-tetramer transition that causes full enzyme-inactivation. This distinct structural feature is absent in mammalian GST isoenzyme counterparts. A flexible loop between residues 113-119 has been reported to be necessary for this tetramerization process. However, here we present structural data of a modified PfGST lacking loop 113-119 at 1.9 Å resolution. Our results clearly show that this loop is not essential for the formation of stable tetramers. Moreover we present for the first time the structures of both, the inactive and tetrameric state at 1.7 Å and the active dimeric state in complex with reduced glutathione at 2.4 Å resolution. Surprisingly, the structure of the inactive tetrameric state reveals a novel non-substrate binding-site occupied by a 2-(N-morpholino) ethane sulfonic acid (MES) molecule in each monomer. Although it is known that the PfGST has the ability to bind lipophilic anionic ligands, the location of the PfGST ligand-binding site remained unclear up to now.


    Organizational Affiliation

    Institute of Biochemistry and Molecular Biology, University of Hamburg, Laboratory of Structural Biology of Infection and Inflammation, c/o DESY, Notkestr. 85, Build. 22a, D-22603 Hamburg, Germany; Institute of Medical Microbiology, Virology and Hygiene, University Medical Center Hamburg-Eppendorf (UKE), D-20246 Hamburg, Germany; The Hamburg Centre for Ultrafast Imaging, Luruper Chaussee 149, D-22761 Hamburg, Germany. Electronic address: markus.perbandt@uni-hamburg.de.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Glutathione S-transferase
A, B
205Plasmodium falciparumMutation(s): 0
Gene Names: GST
EC: 2.5.1.18
Find proteins for Q8MU52 (Plasmodium falciparum)
Go to UniProtKB:  Q8MU52
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
A, B
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
MES
Query on MES

Download SDF File
Download CCD File
A, B
2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.7 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.183
  • Space Group: P 21 21 2
Unit Cell:
Length (Å)Angle (°)
a = 86.400α = 90.00
b = 60.900β = 90.00
c = 74.800γ = 90.00
Software Package:
Software NamePurpose
DENZOdata reduction
PDB_EXTRACTdata extraction
SCALAdata scaling
REFMACrefinement
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-06-24
    Type: Initial release
  • Version 1.1: 2015-09-09
    Type: Database references
  • Version 1.2: 2018-03-07
    Type: Data collection
