4Z0R | pdb_00004z0r

Crystal Structure of the CW domain of ZCWPW2 mutant F78R in complex with histone H3 peptide

PDB DOI: https://doi.org/10.2210/pdb4Z0R/pdb

Classification: PROTEIN BINDING/STRUCTURAL PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2015-03-26 Released: 2015-04-08
Deposition Author(s): Liu, Y., Tempel, W., Bountra, C., Arrowsmith, C.H., Edwards, A.M., Min, J., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free:
0.192 (Depositor), 0.206 (DCC)
R-Value Work:
0.177 (Depositor), 0.192 (DCC)
R-Value Observed:
0.178 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of the CW domain of ZCWPW2 mutant F78R in complex with histone H3 peptide

Liu, Y., Tempel, W., Bountra, C., Arrowsmith, C.H., Edwards, A.M., Min, J.

To be published.

Macromolecule Content

Total Structure Weight: 23.23 kDa
Atom Count: 1,712
Modeled Residue Count: 181
Deposited Residue Count: 193
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Zinc finger CW-type PWWP domain protein 2	A, B, C	59	Homo sapiens	Mutation(s): 1 Gene Names: ZCWPW2
UniProt & NIH Common Fund Data Resources
Find proteins for Q504Y3 (Homo sapiens) Explore Q504Y3 Go to UniProtKB: Q504Y3
GTEx: ENSG00000206559
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q504Y3
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H3.1	D	16	Homo sapiens	Mutation(s): 1
UniProt & NIH Common Fund Data Resources
Find proteins for P68431 (Homo sapiens) Explore P68431 Go to UniProtKB: P68431
PHAROS: P68431 GTEx: ENSG00000197409 ENSG00000197153 ENSG00000278828 ENSG00000275714 ENSG00000273983 ENSG00000274750 ENSG00000275379 ENSG00000277775
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P68431
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain R [auth B] SDF format, chain E [auth A] SDF format, chain AA [auth C] MOL2 format, chain R [auth B] MOL2 format, chain E [auth A] MOL2 format, chain AA [auth C] mmCIF format, chain R [auth B] mmCIF format, chain E [auth A] mmCIF format, chain AA [auth C]	AA [auth C], E [auth A], R [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain AA [auth C] Focus chain E [auth A] Focus chain R [auth B] Interactions & Density Focus chain AA [auth C] Focus chain E [auth A] Focus chain R [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain Z [auth B] MOL2 format, chain Z [auth B] mmCIF format, chain Z [auth B]	Z [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain Z [auth B] Interactions & Density Focus chain Z [auth B]
UNX Query on UNX Download:Ideal Coordinates CCD File SDF format, chain Y [auth B] SDF format, chain X [auth B] SDF format, chain W [auth B] SDF format, chain V [auth B] SDF format, chain U [auth B] SDF format, chain T [auth B] SDF format, chain S [auth B] SDF format, chain Q [auth A] SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain GA [auth D] SDF format, chain G [auth A] SDF format, chain FA [auth D] SDF format, chain EA [auth C] SDF format, chain DA [auth C] SDF format, chain CA [auth C] SDF format, chain BA [auth C] MOL2 format, chain Y [auth B] MOL2 format, chain X [auth B] MOL2 format, chain W [auth B] MOL2 format, chain V [auth B] MOL2 format, chain U [auth B] MOL2 format, chain T [auth B] MOL2 format, chain S [auth B] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain GA [auth D] MOL2 format, chain G [auth A] MOL2 format, chain FA [auth D] MOL2 format, chain EA [auth C] MOL2 format, chain DA [auth C] MOL2 format, chain CA [auth C] MOL2 format, chain BA [auth C] mmCIF format, chain Y [auth B] mmCIF format, chain X [auth B] mmCIF format, chain W [auth B] mmCIF format, chain V [auth B] mmCIF format, chain U [auth B] mmCIF format, chain T [auth B] mmCIF format, chain S [auth B] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain GA [auth D] mmCIF format, chain G [auth A] mmCIF format, chain FA [auth D] mmCIF format, chain EA [auth C] mmCIF format, chain DA [auth C] mmCIF format, chain CA [auth C] mmCIF format, chain BA [auth C]	BA [auth C] CA [auth C] DA [auth C] EA [auth C] FA [auth D] BA [auth C], CA [auth C], DA [auth C], EA [auth C], FA [auth D], G [auth A], GA [auth D], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], S [auth B], T [auth B], U [auth B], V [auth B], W [auth B], X [auth B], Y [auth B]	UNKNOWN ATOM OR ION X		Interactions Focus chain BA [auth C] Focus chain CA [auth C] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain FA [auth D] Focus chain G [auth A] Focus chain GA [auth D] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Interactions & Density Focus chain BA [auth C] Focus chain CA [auth C] Focus chain DA [auth C] Focus chain EA [auth C] Focus chain FA [auth D] Focus chain G [auth A] Focus chain GA [auth D] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
M3L Query on M3L	D	L-PEPTIDE LINKING	C₉ H₂₁ N₂ O₂		LYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.192 (Depositor), 0.206 (DCC)
R-Value Work: 0.177 (Depositor), 0.192 (DCC)
R-Value Observed: 0.178 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 126.659	α = 90
b = 126.659	β = 90
c = 63.271	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data scaling
Coot	model building
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-04-08

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2015-04-08
Type: Initial release
Version 1.1: 2017-11-22
Changes: Derived calculations, Refinement description, Source and taxonomy
Version 1.2: 2023-09-27
Changes: Data collection, Database references, Derived calculations, Refinement description
