4YVW

crystal structure of an enterovirus 71/coxsackievirus A16 chimeric virus-like particle

  • Classification: VIRUS
  • Organism(s): Enterovirus A71
  • Expression System: Saccharomyces cerevisiae
  • Mutation(s):

  • Deposited: 2015-03-20 Released: 2015-04-15
  • Deposition Author(s): Chen, R., Lyu, K.
  • Funding Organization(s): National Natural Science Foundation of China; Ministry of Science and Technology of China

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.8 Å
  • R-Value Free: 0.324
  • R-Value Work: 0.286

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal Structures of Yeast-Produced Enterovirus 71 and Enterovirus 71/Coxsackievirus A16 Chimeric Virus-Like Particles Provide the Structural Basis for Novel Vaccine Design against Hand-Foot-and-Mouth Disease

Lyu, K.He, Y.L.Li, H.Y.Chen, R.

(2015) J.Virol. 89: 6196-6208

  • DOI: 10.1128/JVI.00422-15
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Human enterovirus 71 (EV71) and coxsackievirus A16 (CVA16) are the two major causative agents for hand-foot-and-mouth disease (HFMD). Previously, we demonstrated that a virus-like particle (VLP) for EV71 produced from Saccharomyces cerevisiae is a po ...

    Human enterovirus 71 (EV71) and coxsackievirus A16 (CVA16) are the two major causative agents for hand-foot-and-mouth disease (HFMD). Previously, we demonstrated that a virus-like particle (VLP) for EV71 produced from Saccharomyces cerevisiae is a potential vaccine candidate against EV71 infection, and an EV71/CVA16 chimeric VLP can elicit protective immune responses against both virus infections. Here, we presented the crystal structures of both VLPs, showing that both the linear and conformational neutralization epitopes identified in EV71 are mostly preserved on both VLPs. The replacement of only 4 residues in the VP1 GH loop converted strongly negatively charged surface patches formed by portions of the SP70 epitope in EV71 VLP into a relatively neutral surface in the chimeric VLP, which likely accounted for the additional neutralization capability of the chimeric VLP against CVA16 infection. Such local variations in the amino acid sequences and the surface charge potential are also present in different types of polioviruses. In comparison to EV71 VLP, the chimeric VLP exhibits structural changes at the local site of amino acid replacement and the surface loops of all capsid proteins. This is consistent with the observation that the VP1 GH loop located near the pseudo-3-fold junction is involved in extensive interactions with other capsid regions. Furthermore, portions of VP0 and VP1 in EV71 VLP are at least transiently exposed, revealing the structural flexibility of the VLP. Together, our structural analysis provided insights into the structural basis of enterovirus neutralization and novel vaccine design against HFMD and other enterovirus-associated diseases.


    Organizational Affiliation

    Key Laboratory of Molecular Virology and Immunology, Institut Pasteur of Shanghai, Chinese Academy of Sciences, Shanghai, China rongchen@ips.ac.cn.,Key Laboratory of Molecular Virology and Immunology, Institut Pasteur of Shanghai, Chinese Academy of Sciences, Shanghai, China.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP1
E, A, D, J, M
297Enterovirus A71Mutation(s): 4
Find proteins for F6KTB0 (Enterovirus A71)
Go to UniProtKB:  F6KTB0
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP3
F, B, H, K, N
242Enterovirus A71Mutation(s): 1
Find proteins for F6KTB0 (Enterovirus A71)
Go to UniProtKB:  F6KTB0
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP0
G, C, I, L, O
323Enterovirus A71Mutation(s): 0
Find proteins for F6KTB0 (Enterovirus A71)
Go to UniProtKB:  F6KTB0
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.8 Å
  • R-Value Free: 0.324
  • R-Value Work: 0.286
  • Space Group: P 42 3 2
Unit Cell:
Length (Å)Angle (°)
a = 349.151α = 90.00
b = 349.151β = 90.00
c = 349.151γ = 90.00
Software Package:
Software NamePurpose
PHENIXphasing
SCALEPACKdata scaling
PDB_EXTRACTdata extraction
PHENIXrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2015-03-20
  • Released Date: 2015-04-15
  • Deposition Author(s): Chen, R., Lyu, K.

Funding OrganizationLocationGrant Number
National Natural Science Foundation of ChinaChina31370730
National Natural Science Foundation of ChinaChina31070144
Ministry of Science and Technology of ChinaChina2010CB912403

Revision History

  • Version 1.0: 2015-04-15
    Type: Initial release
  • Version 1.1: 2015-05-27
    Type: Database references
