Biological Assembly 1

 3D View: Structure | 1D-3D View | Electron Density | Validation Report

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Hetero 8-mer - A2B2C2D2 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 8-mer - A7B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 201.61 kDa
• Atom Count: 11974
• Modelled Residue Count: 1047
• Deposited Residue Count: 1302
• Unique protein chains: 4
• Unique nucleic acid chains: 2

4YM5

Crystal structure of the human nucleosome containing 6-4PP (inside)

• PDB DOI: 10.2210/pdb4YM5/pdb
• NDB: 4YM5

• Classification: STRUCTURAL PROTEIN/DNA
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3), Escherichia coli
• Mutation(s): No


• Deposited: 2015-03-06 Released: 2015-12-02
• Deposition Author(s): Osakabe, A., Tachiwana, H., Kagawa, W., Horikoshi, N., Matsumoto, S., Hasegawa, M., Matsumoto, N., Toga, T., Yamamoto, J., Hanaoka, F., Thoma, N.H., Sugasawa, K., Iwai, S., Kurumizaka, H.
• Funding Organization(s): Japan Society for the Promotion of Science, Ministry of Education, Culture, Sports, Science and Technology

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 4.00 Å
• R-Value Free: 0.289
• R-Value Work: 0.203
• R-Value Observed: 0.207

Literature

Structural basis of pyrimidine-pyrimidone (6-4) photoproduct recognition by UV-DDB in the nucleosome

Osakabe, A., Tachiwana, H., Kagawa, W., Horikoshi, N., Matsumoto, S., Hasegawa, M., Matsumoto, N., Toga, T., Yamamoto, J., Hanaoka, F., Thoma, N.H., Sugasawa, K., Iwai, S., Kurumizaka, H.

(2015) Sci Rep 5: 16330-16330

• PubMed: 26573481
• DOI: 10.1038/srep16330
• Primary Citation of Related Structures:
  4YM5, 4YM6


• PubMed Abstract:


UV-DDB, an initiation factor for the nucleotide excision repair pathway, recognizes 6-4PP lesions through a base flipping mechanism. As genomic DNA is almost entirely accommodated within nucleosomes, the flipping of the 6-4PP bases is supposed to be extremely difficult if the lesion occurs in a nucleosome, especially on the strand directly contacting the histone surface. Here we report that UV-DDB binds efficiently to nucleosomal 6-4PPs that are rotationally positioned on the solvent accessible or occluded surface. We determined the crystal structures of nucleosomes containing 6-4PPs in these rotational positions, and found that the 6-4PP DNA regions were flexibly disordered, especially in the strand exposed to the solvent. This characteristic of 6-4PP may facilitate UV-DDB binding to the damaged nucleosome. We present the first atomic-resolution pictures of the detrimental DNA cross-links of neighboring pyrimidine bases within the nucleosome, and provide the mechanistic framework for lesion recognition by UV-DDB in chromatin.

---

Organizational Affiliation:

Laboratory of Structural Biology, Graduate School of Advanced Science and Engineering, Waseda University, 2-2 Wakamatsu-cho, Shinjuku-ku, Tokyo 162-8480, Japan.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H3.1	A, E	139	Homo sapiens	Mutation(s): 0  Gene Names:  HIST1H3A, H3C1, H3FA, H3C2, H3FL, HIST1H3B, H3C3, H3FC HIST1H3C, H3C4, H3FB, HIST1H3D, H3C6, H3FD, HIST1H3E, H3C7, H3FI, HIST1H3F, H3C8, H3FH, HIST1H3G, H3C10, H3FK, HIST1H3H, H3C11, H3FF, HIST1H3I, H3C12, H3FJ, HIST1H3J
UniProt & NIH Common Fund Data Resources
Find proteins for P68431 (Homo sapiens) Explore P68431  Go to UniProtKB:  P68431
PHAROS:  P68431 GTEx:  ENSG00000197409 ENSG00000197153 ENSG00000278828 ENSG00000275714 ENSG00000273983 ENSG00000274750 ENSG00000275379 ENSG00000277775

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H4	B, F	106	Homo sapiens	Mutation(s): 0  Gene Names:  HIST1H4A, H4C1, H4/A, H4FA, H4C2, H4/I, H4FI, HIST1H4B, H4C3, H4/G, H4FG, HIST1H4C, H4C4, H4/B, H4FB, HIST1H4D, H4C5, H4/J, H4FJ, HIST1H4E, H4C6, H4/C, H4FC, HIST1H4F, H4C8, H4/H, H4FH, HIST1H4H, H4C9, H4/M, H4FM, HIST1H4I, H4C11, H4/E, H4FE, HIST1H4J, H4C12, H4/D, H4FD, HIST1H4K, H4C13, H4/K, H4FK, HIST1H4L, H4C14, H4/N, H4F2, H4FN, HIST2H4, HIST2H4A, H4C15, H4/O, H4FO, HIST2H4B, H4-16, HIST4H4
UniProt & NIH Common Fund Data Resources
Find proteins for P62805 (Homo sapiens) Explore P62805  Go to UniProtKB:  P62805
PHAROS:  P62805 GTEx:  ENSG00000274618 ENSG00000197238 ENSG00000197837 ENSG00000158406 ENSG00000278705 ENSG00000197061 ENSG00000270882 ENSG00000270276 ENSG00000273542 ENSG00000277157 ENSG00000276966 ENSG00000276180 ENSG00000278637 ENSG00000275126

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2A type 1-B/E	C, G	133	Homo sapiens	Mutation(s): 0  Gene Names: HIST1H2AB, H2AC4, H2AFM, H2AC8, H2AFA, HIST1H2AE
UniProt & NIH Common Fund Data Resources
Find proteins for P04908 (Homo sapiens) Explore P04908  Go to UniProtKB:  P04908
PHAROS:  P04908 GTEx:  ENSG00000277075 ENSG00000278463

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone H2B type 1-J	D, H	129	Homo sapiens	Mutation(s): 0  Gene Names: HIST1H2BJ, H2BC11, H2BFR
UniProt & NIH Common Fund Data Resources
Find proteins for P06899 (Homo sapiens) Explore P06899  Go to UniProtKB:  P06899
PHAROS:  P06899 GTEx:  ENSG00000124635

Entity ID: 5
Molecule	Chains	Length	Organism	Image
144 mer-DNA	I	144	Homo sapiens

Entity ID: 6
Molecule	Chains	Length	Organism	Image
144-mer DNA	J	144	Homo sapiens

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 4.00 Å
• R-Value Free: 0.289
• R-Value Work: 0.203
• R-Value Observed: 0.207
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 104.193	α = 90
b = 109.356	β = 90
c = 174.417	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data collection
HKL-2000	data scaling
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2015-03-06
• Released Date: 2015-12-02
Deposition Author(s): Osakabe, A., Tachiwana, H., Kagawa, W., Horikoshi, N., Matsumoto, S., Hasegawa, M., Matsumoto, N., Toga, T., Yamamoto, J., Hanaoka, F., Thoma, N.H., Sugasawa, K., Iwai, S., Kurumizaka, H.

---

Funding Organization	Location	Grant Number
Japan Society for the Promotion of Science	Japan	25250023
Ministry of Education, Culture, Sports, Science and Technology	Japan	25131720
Ministry of Education, Culture, Sports, Science and Technology	Japan	25116002

Revision History

• Version 1.0: 2015-12-02
  Type: Initial release

• Version 1.1: 2020-02-05
  Changes: Data collection, Derived calculations
