4YLO

E. coli Transcription Initiation Complex - 16-bp spacer and 4-nt RNA

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 6.00 Å
  • R-Value Free: 0.314
  • R-Value Work: 0.227
  • R-Value Observed: 0.232

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history.


Literature

Crystal Structures of the E. coli Transcription Initiation Complexes with a Complete Bubble.

Zuo, Y., Steitz, T.A.

(2015) Mol Cell 58: 534-540

  • DOI: https://doi.org/10.1016/j.molcel.2015.03.010
  • Primary Citation of Related Structures:
    4YLN, 4YLO, 4YLP

  • PubMed Abstract:

    • During transcription initiation, RNA polymerase binds to promoter DNA to form an initiation complex containing a DNA bubble and enters into abortive cycles of RNA synthesis before escaping the promoter to transit into the elongation phase for processive RNA synthesis ...

    During transcription initiation, RNA polymerase binds to promoter DNA to form an initiation complex containing a DNA bubble and enters into abortive cycles of RNA synthesis before escaping the promoter to transit into the elongation phase for processive RNA synthesis. Here we present the crystal structures of E. coli transcription initiation complexes containing a complete transcription bubble and de novo synthesized RNA oligonucleotides at about 6-Å resolution. The structures show how RNA polymerase recognizes DNA promoters that contain spacers of different lengths and reveal a bridging interaction between the 5'-triphosphate of the nascent RNA and the σ factor that may function to stabilize the short RNA-DNA hybrids during the early stage of transcription initiation. The conformation of the RNA oligonucleotides and the paths of the DNA strands in the complete initiation complexes provide insights into the mechanism that controls both the abortive and productive RNA synthesis.

    Organizational Affiliation:

    Department of Molecular Biophysics and Biochemistry, Yale University, New Haven, CT 06520, USA; Howard Hughes Medical Institute, New Haven, CT 06510, USA; Department of Chemistry, Yale University, New Haven, CT 06520, USA. Electronic address: thomas.steitz@yale.edu.



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit alpha242Escherichia coliMutation(s): 0
Gene Names: rpoA, EcE24377A_3778
EC: 2.7.7.6
UniProt
Find proteins for A7ZSI4 (Escherichia coli O139:H28 (strain E24377A / ETEC))
Explore A7ZSI4
Go to UniProtKB:  A7ZSI4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA7ZSI4
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit betaC,
L [auth I],
U [auth O]		1,342Escherichia coliMutation(s): 0
Gene Names: rpoB, EcE24377A_4528
EC: 2.7.7.6
UniProt
Find proteins for A7ZUK1 (Escherichia coli O139:H28 (strain E24377A / ETEC))
Explore A7ZUK1
Go to UniProtKB:  A7ZUK1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA7ZUK1
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta'D,
M [auth J],
V [auth P]		1,407Escherichia coliMutation(s): 0
Gene Names: rpoC, EcE24377A_4529
EC: 2.7.7.6
UniProt
Find proteins for P0A8T7 (Escherichia coli (strain K12))
Explore P0A8T7
Go to UniProtKB:  P0A8T7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A8T7
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit omegaE,
N [auth K],
W [auth Q]		90Escherichia coliMutation(s): 0
Gene Names: rpoZ, EcE24377A_4152
EC: 2.7.7.6
UniProt
Find proteins for A7ZTK1 (Escherichia coli O139:H28 (strain E24377A / ETEC))
Explore A7ZTK1
Go to UniProtKB:  A7ZTK1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA7ZTK1
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
RNA polymerase sigma factor RpoDF,
O [auth L],
X [auth R]		628Escherichia coliMutation(s): 0
Gene Names: rpoD, alt, b3067, JW3039
UniProt
Find proteins for P00579 (Escherichia coli (strain K12))
Explore P00579
Go to UniProtKB:  P00579
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00579
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsLengthOrganismImage
NT strand DNA (49-MER)G [auth 1],
P [auth 4],
Y [auth 7]		49synthetic construct
Protein Feature View
Expand
  • Reference Sequence
Find similar nucleic acids by:
(by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsLengthOrganismImage
T strand DNA (49-MER)H [auth 2],
Q [auth 5],
Z [auth 8]		49synthetic construct
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 8
MoleculeChainsLengthOrganismImage
RNA (5'-D(*(GTP))-R(P*AP*GP*U)-3')AA [auth 9],
I [auth 3],
R [auth 6]		4synthetic construct
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 6.00 Å
  • R-Value Free: 0.314
  • R-Value Work: 0.227
  • R-Value Observed: 0.232
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 240.888α = 90
b = 208.174β = 119.31
c = 256.323γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM057510

Revision History  (Full details and data files)

  • Version 1.0: 2015-04-22
    Type: Initial release
  • Version 1.1: 2015-04-29
    Changes: Database references
  • Version 1.2: 2015-05-20
    Changes: Database references
  • Version 1.3: 2017-09-06
    Changes: Author supporting evidence, Database references, Derived calculations, Source and taxonomy
  • Version 1.4: 2019-12-25
    Changes: Author supporting evidence
