4XWX | pdb_00004xwx

Crystal structure of the PTB domain of SHC

PDB DOI: https://doi.org/10.2210/pdb4XWX/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2015-01-29 Released: 2015-02-25
Deposition Author(s): Chaikuad, A., Tallant, C., Krojer, T., Dixon-Clarke, S., von Delft, F., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Knapp, S., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.87 Å
R-Value Free:
0.191 (Depositor), 0.205 (DCC)
R-Value Work:
0.168 (Depositor), 0.176 (DCC)
R-Value Observed:
0.169 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4XWX

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of the PTB domain of SHC

Chaikuad, A., Tallant, C., Krojer, T., Dixon-Clarke, S., von Delft, F., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Knapp, S., Structural Genomics Consortium (SGC)

To be published.

Macromolecule Content

Total Structure Weight: 18.53 kDa
Atom Count: 1,338
Modeled Residue Count: 160
Deposited Residue Count: 167
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
SHC-transforming protein 1	A	167	Homo sapiens	Mutation(s): 0 Gene Names: SHC1, SHC, SHCA
UniProt & NIH Common Fund Data Resources
Find proteins for P29353 (Homo sapiens) Explore P29353 Go to UniProtKB: P29353
PHAROS: P29353 GTEx: ENSG00000160691
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P29353
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A] C [auth A] D [auth A] E [auth A] F [auth A] B [auth A], C [auth A], D [auth A], E [auth A], F [auth A], G [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.87 Å
R-Value Free: 0.191 (Depositor), 0.205 (DCC)
R-Value Work: 0.168 (Depositor), 0.176 (DCC)
R-Value Observed: 0.169 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 64.91	α = 90
b = 126.79	β = 90
c = 50.4	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
MOSFLM	data reduction
SCALA	data scaling
SHARP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-02-25

Deposition Author(s):

Dixon-Clarke, S.

Arrowsmith, C.H.

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2015-02-25
Type: Initial release
Version 1.1: 2024-05-08
Changes: Data collection, Database references, Derived calculations
