4XW3

Crystal structure of the SPRY domain of the human DEAD-box protein DDX1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.200

wwPDB Validation 3D Report Full Report


This is version 2.0 of the entry. See complete history

Literature

Structure of the SPRY domain of the human RNA helicase DDX1, a putative interaction platform within a DEAD-box protein.

Kellner, J.N.Meinhart, A.

(2015) Acta Crystallogr.,Sect.F 71: 1176-1188

  • DOI: 10.1107/S2053230X15013709

  • PubMed Abstract:
  • The human RNA helicase DDX1 in the DEAD-box family plays an important role in RNA processing and has been associated with HIV-1 replication and tumour progression. Whereas previously described DEAD-box proteins have a structurally conserved core, DDX ...

    The human RNA helicase DDX1 in the DEAD-box family plays an important role in RNA processing and has been associated with HIV-1 replication and tumour progression. Whereas previously described DEAD-box proteins have a structurally conserved core, DDX1 shows a unique structural feature: a large SPRY-domain insertion in its RecA-like consensus fold. SPRY domains are known to function as protein-protein interaction platforms. Here, the crystal structure of the SPRY domain of human DDX1 (hDSPRY) is reported at 2.0 Å resolution. The structure reveals two layers of concave, antiparallel β-sheets that stack onto each other and a third β-sheet beneath the β-sandwich. A comparison with SPRY-domain structures from other eukaryotic proteins showed that the general β-sandwich fold is conserved; however, differences were detected in the loop regions, which were identified in other SPRY domains to be essential for interaction with cognate partners. In contrast, in hDSPRY these loop regions are not strictly conserved across species. Interestingly, though, a conserved patch of positive surface charge is found that may replace the connecting loops as a protein-protein interaction surface. The data presented here comprise the first structural information on DDX1 and provide insights into the unique domain architecture of this DEAD-box protein. By providing the structure of a putative interaction domain of DDX1, this work will serve as a basis for further studies of the interaction network within the hetero-oligomeric complexes of DDX1 and of its recruitment to the HIV-1 Rev protein as a viral replication factor.


    Organizational Affiliation

    Department of Biomolecular Mechanisms, Max Planck Institute for Medical Research, Jahnstrasse 29, 69120 Heidelberg, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
ATP-dependent RNA helicase DDX1
A, B
221Homo sapiensMutation(s): 0
Gene Names: DDX1
EC: 3.6.4.13
Find proteins for Q92499 (Homo sapiens)
Go to Gene View: DDX1
Go to UniProtKB:  Q92499
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.200
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 45.060α = 90.00
b = 76.140β = 90.00
c = 122.660γ = 90.00
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
XDSdata reduction
REFMACrefinement
Cootmodel building
PHASERphasing
XSCALEdata scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanyME 3135/1-2

Revision History

  • Version 1.0: 2015-09-09
    Type: Initial release
  • Version 2.0: 2017-09-06
    Type: Atomic model, Author supporting evidence
