4WIC

Immediate-early 1 protein (IE1) of rhesus macaque cytomegalovirus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.212

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Controlled crystal dehydration triggers a space-group switch and shapes the tertiary structure of cytomegalovirus immediate-early 1 (IE1) protein.

Klingl, S.Scherer, M.Stamminger, T.Muller, Y.A.

(2015) Acta Crystallogr.,Sect.D 71: 1493-1504

  • DOI: 10.1107/S1399004715008792

  • PubMed Abstract:
  • Cytomegalovirus immediate-early 1 (IE1) protein is a key viral effector protein that reprograms host cells. Controlled dehydration experiments with IE1 crystals not only extended their diffraction limit from 2.85 to 2.3 Å resolution but also triggere ...

    Cytomegalovirus immediate-early 1 (IE1) protein is a key viral effector protein that reprograms host cells. Controlled dehydration experiments with IE1 crystals not only extended their diffraction limit from 2.85 to 2.3 Å resolution but also triggered a monoclinic to tetragonal space-group transition with only minor alterations in the unit-cell parameters. An analysis of the pre-dehydration and post-dehydration crystal structures shows how dehydration rearranges the packing of IE1 molecules to meet the unit-cell constraints of the higher lattice symmetry. The transition from P21 to P43 reduces the number of copies in the asymmetric unit from four to two, and molecules previously related by noncrystallographic symmetry merge into identical crystallographic copies in the tetragonal space group. At the same time, dehydration considerably alters the tertiary structure of one of the two remaining IE1 chains in the asymmetric unit. It appears that this conformational switch is required to compensate for a transition that is assumed to be unfavourable, namely from a highly preferred to a rarely observed space group. At the same time, the dehydration-triggered molecular reshaping could reveal an inherent molecular flexibility that possibly informs on the biological function of IE1, namely on its binding to target proteins from the host cell.


    Organizational Affiliation

    Division of Biotechnology, Department of Biology, Friedrich-Alexander University Erlangen-Nuremberg, Henkestrasse 91, 91052 Erlangen, Germany.,Institute for Clinical and Molecular Virology, Friedrich-Alexander University Erlangen-Nuremberg, Schlossgarten 4, 91054 Erlangen, Germany.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
RhUL123
A, B, C, D
365Macacine betaherpesvirus 3Mutation(s): 0
Find proteins for Q2FAE9 (Macacine betaherpesvirus 3)
Go to UniProtKB:  Q2FAE9
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.259
  • R-Value Work: 0.212
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 57.950α = 90.00
b = 278.550β = 90.90
c = 61.620γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHENIXrefinement
SHARPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research FoundationGermanySFB796

Revision History

  • Version 1.0: 2015-07-15
    Type: Initial release
  • Version 1.1: 2017-09-06
    Type: Author supporting evidence
