Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 15.68 kDa
• Atom Count: 1,130
• Modelled Residue Count: 129
• Deposited Residue Count: 129
• Unique protein chains: 1

 4W96

Crystal structure of cross-linked tetragonal hen egg white lysozyme soaked with 5mM [Ru(CO)3Cl2]2 followed by the reaction in deoxy-myoglobin solution

• PDB DOI: 10.2210/pdb4W96/pdb

• Classification: HYDROLASE
• Organism(s): Gallus gallus
• Expression System: Gallus gallus
• Mutation(s): No


• Deposited: 2014-08-27 Released: 2014-12-31
• Deposition Author(s): Tabe, H., Fujita, K., Abe, S., Tsujimoto, M., Kuchimaru, T., Kizaka-Kondo, S., Takano, M., Kitagawa, S., Ueno, T.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free: 0.227
• R-Value Work: 0.195
• R-Value Observed: 0.196

Literature

Preparation of a Cross-Linked Porous Protein Crystal Containing Ru Carbonyl Complexes as a CO-Releasing Extracellular Scaffold

Tabe, H., Fujita, K., Abe, S., Tsujimoto, M., Kuchimaru, T., Kizaka-Kondoh, S., Takano, M., Kitagawa, S., Ueno, T.

(2015) Inorg Chem 54: 215-220

• PubMed: 25494847
• DOI: 10.1021/ic502159x
• Primary Citation of Related Structures:
  4W94, 4W96


• PubMed Abstract:


Protein crystals generally are stable solid protein assemblies. Certain protein crystals are suitable for use as nanovessels for immobilizing metal complexes. Here we report the preparation of ruthenium carbonyl-incorporated cross-linked hen egg white lysozyme crystals (Ru·CL-HEWL). Ru·CL-HEWL retains a Ru carbonyl moiety that can release CO, although a composite of Ru carbonyl-HEWL dissolved in buffer solution (Ru·HEWL) does not release CO. We found that treatment of cells with Ru·CL-HEWL significantly increased nuclear factor kappa B (NF-κB) activity as a cellular response to CO. These results demonstrate that Ru·CL-HEWL has potential for use as an artificial extracellular scaffold suitable for transport and release of a gas molecule.

---

Organizational Affiliation:

Graduate School of Engineering, Kyoto University, Katsura , Nishikyo-ku, Kyoto 615-8510, Japan.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysozyme C	A	129	Gallus gallus	Mutation(s): 0  Gene Names: LYZ EC: 3.2.1.17
UniProt
Find proteins for P00698 (Gallus gallus) Explore P00698  Go to UniProtKB:  P00698

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
RU1	H [auth A]	bis(oxidaniumylidynemethyl)ruthenium(2+) C2 O2 Ru HLYOBVRGNSSECA-UHFFFAOYSA-N
RU	K [auth A], L [auth A], N [auth A], O [auth A], P [auth A], Q [auth A], S [auth A], T [auth A]	RUTHENIUM ION Ru BPEVHDGLPIIAGH-UHFFFAOYSA-N
DMF	B [auth A]	DIMETHYLFORMAMIDE C3 H7 N O ZMXDDKWLCZADIW-UHFFFAOYSA-N
CL	C [auth A], D [auth A], E [auth A], F [auth A], I [auth A], J [auth A], M [auth A], R [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA	G [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free: 0.227
• R-Value Work: 0.195
• R-Value Observed: 0.196
• Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.011	α = 90
b = 79.011	β = 90
c = 36.994	γ = 90

Software Package:

Software Name	Purpose
DENZO	data collection
SCALEPACK	data reduction
MOLREP	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
DENZO	data reduction
SCALEPACK	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-12-31
Deposition Author(s): Tabe, H., Fujita, K., Abe, S., Tsujimoto, M., Kuchimaru, T., Kizaka-Kondo, S., Takano, M., Kitagawa, S., Ueno, T.

Revision History

• Version 1.0: 2014-12-31
  Type: Initial release

• Version 1.1: 2015-01-14
  Changes: Database references
• Version 1.2: 2020-01-29
  Changes: Advisory, Data collection, Database references, Derived calculations, Source and taxonomy
