4USX

The Structure of the C-terminal YadA-like domain of BPSL2063 from Burkholderia pseudomallei


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.169

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Selecting Soluble/Foldable Protein Domains Through Single-Gene or Genomic Orf Filtering: Structure of the Head Domain of Burkholderia Pseudomallei Antigen Bpsl2063.

Gourlay, L.J.Peano, C.Deantonio, C.Perletti, L.Pietrelli, A.Villa, R.Matterazzo, E.Lassaux, P.Santoro, C.Puccio, S.Sblattero, D.Bolognesi, M.

(2015) Acta Crystallogr.,Sect.D 71: 2227

  • DOI: 10.1107/S1399004715015680

  • PubMed Abstract:
  • The 1.8 Å resolution crystal structure of a conserved domain of the potential Burkholderia pseudomallei antigen and trimeric autotransporter BPSL2063 is presented as a structural vaccinology target for melioidosis vaccine development. Since BPSL2063 ...

    The 1.8 Å resolution crystal structure of a conserved domain of the potential Burkholderia pseudomallei antigen and trimeric autotransporter BPSL2063 is presented as a structural vaccinology target for melioidosis vaccine development. Since BPSL2063 (1090 amino acids) hosts only one conserved domain, and the expression/purification of the full-length protein proved to be problematic, a domain-filtering library was generated using β-lactamase as a reporter gene to select further BPSL2063 domains. As a result, two domains (D1 and D2) were identified and produced in soluble form in Escherichia coli. Furthermore, as a general tool, a genomic open reading frame-filtering library from the B. pseudomallei genome was also constructed to facilitate the selection of domain boundaries from the entire ORFeome. Such an approach allowed the selection of three potential protein antigens that were also produced in soluble form. The results imply the further development of ORF-filtering methods as a tool in protein-based research to improve the selection and production of soluble proteins or domains for downstream applications such as X-ray crystallography.


    Organizational Affiliation

    Institute of Biomedical Technologies, National Research Council, Via Fratelli Cervi 93, 20090 Segrate, Italy.,Department of Biosciences, University of Milan, Via Celoria 26, 20133 Milan, Italy.,Department of Life Sciences, University of Trieste, Via Weiss 2, 34128 Trieste, Italy.,Department of Health Sciences and IRCAD, University of Eastern Piedmont, Via Solaroli 17, 28100 Novara, Italy.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
TRIMERIC AUTOTRANSPORTER ADHESIN
A, B, C
371Burkholderia pseudomallei (strain K96243)Mutation(s): 0
Find proteins for Q63TA4 (Burkholderia pseudomallei (strain K96243))
Go to UniProtKB:  Q63TA4
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MG
Query on MG

Download SDF File
Download CCD File
A, B, C
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.8 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.169
  • Space Group: P 1 21 1
Unit Cell:
Length (Å)Angle (°)
a = 63.115α = 90.00
b = 58.852β = 104.65
c = 74.407γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
SCALAdata scaling
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2015-07-22
    Type: Initial release
  • Version 1.1: 2015-11-11
    Type: Database references
