4UQZ

Coevolution of the ATPase ClpV, the TssB-TssC Sheath and the Accessory HsiE Protein Distinguishes Two Type VI Secretion Classes


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.599 Å
  • R-Value Free: 0.221
  • R-Value Work: 0.188

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Coevolution of the ATPase Clpv, the Sheath Proteins Tssb and Tssc and the Accessory Protein Tagj/Hsie1 Distinguishes Type Vi Secretion Classes.

Forster, A.Planamente, S.Manoli, E.Lossi, N.S.Freemont, P.S.Filloux, A.

(2014) RNA 20: 1955

  • DOI: 10.1074/jbc.M114.600510
  • Primary Citation of Related Structures:  4UQW, 4UQX, 4UQY

  • PubMed Abstract:
  • The type VI secretion system (T6SS) is a bacterial nanomachine for the transport of effector molecules into prokaryotic and eukaryotic cells. It involves the assembly of a tubular structure composed of TssB and TssC that is similar to the tail sheath ...

    The type VI secretion system (T6SS) is a bacterial nanomachine for the transport of effector molecules into prokaryotic and eukaryotic cells. It involves the assembly of a tubular structure composed of TssB and TssC that is similar to the tail sheath of bacteriophages. The sheath contracts to provide the energy needed for effector delivery. The AAA(+) ATPase ClpV disassembles the contracted sheath, which resets the systems for reassembly of an extended sheath that is ready to fire again. This mechanism is crucial for T6SS function. In Vibrio cholerae, ClpV binds the N terminus of TssC within a hydrophobic groove. In this study, we resolved the crystal structure of the N-terminal domain of Pseudomonas aeruginosa ClpV1 and observed structural alterations in the hydrophobic groove. The modification in the ClpV1 groove is matched by a change in the N terminus of TssC, suggesting the existence of distinct T6SS classes. An accessory T6SS component, TagJ/HsiE, exists predominantly in one of the classes. Using bacterial two-hybrid approaches, we showed that the P. aeruginosa homolog HsiE1 interacts strongly with ClpV1. We then resolved the crystal structure of HsiE1 in complex with the N terminus of HsiB1, a TssB homolog and component of the contractile sheath. Phylogenetic analysis confirmed that these differences distinguish T6SS classes that resulted from a functional co-evolution between TssB, TssC, TagJ/HsiE, and ClpV. The interaction of TagJ/HsiE with the sheath as well as with ClpV suggests an alternative mode of disassembly in which HsiE recruits the ATPase to the sheath.


    Organizational Affiliation

    From the Centre for Structural Biology and.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
HSIE1
A
261Pseudomonas aeruginosa (strain ATCC 15692 / PAO1 / 1C / PRS 101 / LMG 12228)N/A
Find proteins for Q9I746 (Pseudomonas aeruginosa (strain ATCC 15692 / PAO1 / 1C / PRS 101 / LMG 12228))
Go to UniProtKB:  Q9I746
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
HSIB1
B
172Pseudomonas aeruginosa (strain ATCC 15692 / PAO1 / 1C / PRS 101 / LMG 12228)N/A
Find proteins for Q9I749 (Pseudomonas aeruginosa (strain ATCC 15692 / PAO1 / 1C / PRS 101 / LMG 12228))
Go to UniProtKB:  Q9I749
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ACT
Query on ACT

Download SDF File
Download CCD File
A
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.599 Å
  • R-Value Free: 0.221
  • R-Value Work: 0.188
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 52.112α = 90.00
b = 67.323β = 90.00
c = 94.025γ = 90.00
Software Package:
Software NamePurpose
XDSdata reduction
PHENIXrefinement
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-10-22
    Type: Initial release
  • Version 1.1: 2014-12-03
    Type: Database references
