Coevolution of the ATPase ClpV, the TssB-TssC Sheath and the Accessory HsiE Protein Distinguishes Two Type VI Secretion Classes

Experimental Data Snapshot

  • Resolution: 1.50 Å
  • R-Value Free: 0.181
  • R-Value Work: 0.159
  • R-Value Observed: 0.160

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Coevolution of the ATPase Clpv, the Sheath Proteins Tssb and Tssc and the Accessory Protein Tagj/Hsie1 Distinguishes Type Vi Secretion Classes.

Forster, A.Planamente, S.Manoli, E.Lossi, N.S.Freemont, P.S.Filloux, A.

(2014) J Biol Chem 289: 33032

  • DOI: https://doi.org/10.1074/jbc.M114.600510
  • Primary Citation of Related Structures:
    4UQW, 4UQX, 4UQY, 4UQZ

  • PubMed Abstract:

    The type VI secretion system (T6SS) is a bacterial nanomachine for the transport of effector molecules into prokaryotic and eukaryotic cells. It involves the assembly of a tubular structure composed of TssB and TssC that is similar to the tail sheath of bacteriophages. The sheath contracts to provide the energy needed for effector delivery. The AAA(+) ATPase ClpV disassembles the contracted sheath, which resets the systems for reassembly of an extended sheath that is ready to fire again. This mechanism is crucial for T6SS function. In Vibrio cholerae, ClpV binds the N terminus of TssC within a hydrophobic groove. In this study, we resolved the crystal structure of the N-terminal domain of Pseudomonas aeruginosa ClpV1 and observed structural alterations in the hydrophobic groove. The modification in the ClpV1 groove is matched by a change in the N terminus of TssC, suggesting the existence of distinct T6SS classes. An accessory T6SS component, TagJ/HsiE, exists predominantly in one of the classes. Using bacterial two-hybrid approaches, we showed that the P. aeruginosa homolog HsiE1 interacts strongly with ClpV1. We then resolved the crystal structure of HsiE1 in complex with the N terminus of HsiB1, a TssB homolog and component of the contractile sheath. Phylogenetic analysis confirmed that these differences distinguish T6SS classes that resulted from a functional co-evolution between TssB, TssC, TagJ/HsiE, and ClpV. The interaction of TagJ/HsiE with the sheath as well as with ClpV suggests an alternative mode of disassembly in which HsiE recruits the ATPase to the sheath.

  • Organizational Affiliation

    the Medical Research Council Centre for Molecular Bacteriology and Infection, Department of Life Sciences, Imperial College London, London SW7 2AZ, United Kingdom.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B
163Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: clpV1PA0090
Find proteins for Q9I742 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q9I742
Go to UniProtKB:  Q9I742
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9I742
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on BEN

Download Ideal Coordinates CCD File
C7 H8 N2
Experimental Data & Validation

Experimental Data

  • Resolution: 1.50 Å
  • R-Value Free: 0.181
  • R-Value Work: 0.159
  • R-Value Observed: 0.160
  • Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.53α = 90
b = 90.53β = 90
c = 54.31γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-10-22
    Type: Initial release
  • Version 1.1: 2014-12-10
    Changes: Database references
