4QIW

Crystal structure of euryarchaeal RNA polymerase from Thermococcus kodakarensis


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.50 Å
  • R-Value Free: 0.316
  • R-Value Work: 0.277
  • R-Value Observed: 0.279

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

The X-ray crystal structure of the euryarchaeal RNA polymerase in an open-clamp configuration.

Jun, S.H.Hirata, A.Kanai, T.Santangelo, T.J.Imanaka, T.Murakami, K.S.

(2014) Nat Commun 5: 5132-5132

  • DOI: https://doi.org/10.1038/ncomms6132
  • Primary Citation of Related Structures:
    4QIW, 4QJV

  • PubMed Abstract:

    The archaeal transcription apparatus is closely related to the eukaryotic RNA polymerase II (Pol II) system. Archaeal RNA polymerase (RNAP) and Pol II evolved from a common ancestral structure and the euryarchaeal RNAP is the simplest member of the extant archaeal-eukaryotic RNAP family. Here we report the first crystal structure of euryarchaeal RNAP from Thermococcus kodakarensis (Tko). This structure reveals that the clamp domain is able to swing away from the main body of RNAP in the presence of the Rpo4/Rpo7 stalk by coordinated movements of these domains. More detailed structure-function analysis of yeast Pol II and Tko RNAP identifies structural additions to Pol II that correspond to the binding sites of Pol II-specific general transcription factors including TFIIF, TFIIH and Mediator. Such comparisons provide a framework for dissecting interactions between RNAP and these factors during formation of the pre-initiation complex.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Biology, The Center for RNA Molecular Biology, The Pennsylvania State University, University Park, Pennsylvania 16802, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymeraseA,
L [auth I]
906Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JE33 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JE33
Go to UniProtKB:  Q5JE33
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JE33
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymeraseB,
M [auth J]
1,123Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JE32 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JE32
Go to UniProtKB:  Q5JE32
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JE32
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit A''C,
N [auth M]
391Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JE34 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JE34
Go to UniProtKB:  Q5JE34
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JE34
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit D
D, O
259Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JJF4 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JJF4
Go to UniProtKB:  Q5JJF4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JJF4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase, subunit E'E,
P [auth Q]
190Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JIY4 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JIY4
Go to UniProtKB:  Q5JIY4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JIY4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase, subunit FF,
Q [auth R]
122Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JI52 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JI52
Go to UniProtKB:  Q5JI52
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JI52
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit HG [auth H],
R [auth S]
82Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JE31 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JE31
Go to UniProtKB:  Q5JE31
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JE31
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit KH [auth K],
S [auth T]
57Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JJD0 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JJD0
Go to UniProtKB:  Q5JJD0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JJD0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit LI [auth L],
T [auth U]
100Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JE88 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JE88
Go to UniProtKB:  Q5JE88
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JE88
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit NJ [auth N],
U [auth V]
65Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JJC9 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JJC9
Go to UniProtKB:  Q5JJC9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JJC9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit PK [auth P],
V [auth W]
49Thermococcus kodakarensis KOD1Mutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5JDM8 (Thermococcus kodakarensis (strain ATCC BAA-918 / JCM 12380 / KOD1))
Explore Q5JDM8
Go to UniProtKB:  Q5JDM8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5JDM8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
AA [auth B]
BA [auth N]
CA [auth P]
EA [auth I]
FA [auth I]
AA [auth B],
BA [auth N],
CA [auth P],
EA [auth I],
FA [auth I],
HA [auth J],
IA [auth V],
JA [auth W],
X [auth A],
Y [auth A]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
DA [auth I],
GA [auth I],
W [auth A],
Z [auth A]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.50 Å
  • R-Value Free: 0.316
  • R-Value Work: 0.277
  • R-Value Observed: 0.279
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 112.975α = 90
b = 206.606β = 90
c = 365.157γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
PHENIXmodel building
PHENIXrefinement
DENZOdata reduction
SCALEPACKdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-10-08
    Type: Initial release
  • Version 1.1: 2014-11-26
    Changes: Database references
