Structure of Human Polyomavirus 9 VP1 pentamer in complex with N-glycolylneuraminic acid containing 3'-sialyllactosamine

Experimental Data Snapshot

  • Resolution: 2.10 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.184
  • R-Value Observed: 0.186

wwPDB Validation   3D Report Full Report

This is version 2.1 of the entry. See complete history


Crystallographic and glycan microarray analysis of human polyomavirus 9 VP1 identifies N-glycolyl neuraminic acid as a receptor candidate.

Khan, Z.M.Liu, Y.Neu, U.Gilbert, M.Ehlers, B.Feizi, T.Stehle, T.

(2014) J Virol 88: 6100-6111

  • DOI: https://doi.org/10.1128/JVI.03455-13
  • Primary Citation of Related Structures:
    4POQ, 4POR, 4POS, 4POT

  • PubMed Abstract:

    Human polyomavirus 9 (HPyV9) is a closely related homologue of simian B-lymphotropic polyomavirus (LPyV). In order to define the architecture and receptor binding properties of HPyV9, we solved high-resolution crystal structures of its major capsid protein, VP1, in complex with three putative oligosaccharide receptors identified by glycan microarray screening. Comparison of the properties of HPyV9 VP1 with the known structure and glycan-binding properties of LPyV VP1 revealed that both viruses engage short sialylated oligosaccharides, but small yet important differences in specificity were detected. Surprisingly, HPyV9 VP1 preferentially binds sialyllactosamine compounds terminating in 5-N-glycolyl neuraminic acid (Neu5Gc) over those terminating in 5-N-acetyl neuraminic acid (Neu5Ac), whereas LPyV does not exhibit such a preference. The structural analysis demonstrated that HPyV9 makes specific contacts, via hydrogen bonds, with the extra hydroxyl group present in Neu5Gc. An equivalent hydrogen bond cannot be formed by LPyV VP1. The most common sialic acid in humans is 5-N-acetyl neuraminic acid (Neu5Ac), but various modifications give rise to more than 50 different sialic acid variants that decorate the cell surface. Unlike most mammals, humans cannot synthesize the sialic acid variant 5-N-glycolyl neuraminic acid (Neu5Gc) due to a gene defect. Humans can, however, still acquire this compound from dietary sources. The role of Neu5Gc in receptor engagement and in defining viral tropism is only beginning to emerge, and structural analyses defining the differences in specificity for Neu5Ac and Neu5Gc are still rare. Using glycan microarray screening and high-resolution protein crystallography, we have examined the receptor specificity of a recently discovered human polyomavirus, HPyV9, and compared it to that of the closely related simian polyomavirus LPyV. Our study highlights critical differences in the specificities of both viruses, contributing to an enhanced understanding of the principles that underlie pathogen selectivity for modified sialic acids.

  • Organizational Affiliation

    Interfaculty Institute of Biochemistry, University of Tuebingen, Tuebingen, Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
A, B, C, D, E
A, B, C, D, E, F, G, H, I, J
278Human polyomavirus 9Mutation(s): 0
Gene Names: gp3vp1
Find proteins for E9NQ90 (Human polyomavirus 9)
Explore E9NQ90
Go to UniProtKB:  E9NQ90
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupE9NQ90
Sequence Annotations
  • Reference Sequence


Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
N-glycolyl-alpha-neuraminic acid-(2-3)-beta-D-galactopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
K, L, M, N, O
K, L, M, N, O, P, Q, R, S, T
Glycosylation Resources
GlyTouCan:  G08169IN
GlyCosmos:  G08169IN
GlyGen:  G08169IN
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on EDO

Download Ideal Coordinates CCD File
AA [auth B]
AB [auth G]
BB [auth G]
CB [auth G]
DA [auth C]
AA [auth B],
AB [auth G],
BB [auth G],
CB [auth G],
DA [auth C],
EA [auth C],
FA [auth C],
FB [auth H],
GA [auth C],
GB [auth H],
JA [auth D],
JB [auth I],
KA [auth D],
KB [auth I],
LA [auth D],
MA [auth D],
NB [auth J],
OB [auth J],
PA [auth E],
PB [auth J],
QA [auth E],
TA [auth F],
UA [auth F],
V [auth A],
VA [auth F],
W [auth A],
YA [auth G],
Z [auth B],
ZA [auth G]
C2 H6 O2
Query on IPA

Download Ideal Coordinates CCD File
BA [auth B]
DB [auth G]
HA [auth C]
HB [auth H]
LB [auth I]
BA [auth B],
DB [auth G],
HA [auth C],
HB [auth H],
LB [auth I],
NA [auth D],
QB [auth J],
RA [auth E],
WA [auth F],
X [auth A]
C3 H8 O
Query on CA

Download Ideal Coordinates CCD File
CA [auth C]
EB [auth H]
IA [auth D]
IB [auth I]
MB [auth J]
CA [auth C],
EB [auth H],
IA [auth D],
IB [auth I],
MB [auth J],
OA [auth E],
SA [auth F],
U [auth A],
XA [auth G],
Y [auth B]
Experimental Data & Validation

Experimental Data

  • Resolution: 2.10 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.184
  • R-Value Observed: 0.186
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 103.4α = 90
b = 177.65β = 90
c = 198.65γ = 90
Software Package:
Software NamePurpose
RemDAqdata collection
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-04-09
    Type: Initial release
  • Version 1.1: 2014-11-26
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
  • Version 2.1: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
