4OIA

Crystal Structure of ICAM-5 D1-D4 ectodomain fragment, Space Group P4322


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.70 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.230
  • R-Value Observed: 0.233

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.1 of the entry. See complete history


Literature

Crystal structures of an ICAM-5 ectodomain fragment show electrostatic-based homophilic adhesions.

Recacha, R.Jimenez, D.Tian, L.Barredo, R.Gahmberg, C.G.Casasnovas, J.M.

(2014) Acta Crystallogr D Biol Crystallogr 70: 1934-1943

  • DOI: https://doi.org/10.1107/S1399004714009468
  • Primary Citation of Related Structures:
    4OI9, 4OIA, 4OIB

  • PubMed Abstract:

    Intercellular cell adhesion molecule-5 (ICAM-5) is a member of the ICAM subfamily that is exclusively expressed in the telencephalon region of the brain. The crystal structure of the four most N-terminal glycosylated domains (D1-D4) of ICAM-5 was determined in three different space groups and the D1-D5 fragment was modelled. The structures showed a curved molecule with two pronounced interdomain bends between D2 and D3 and between D3 and D4, as well as some interdomain flexibility. In contrast to ICAM-1, ICAM-5 has patches of positive and negative electrostatic charge at D1-D2 and at D3-D5, respectively. ICAM-5 can mediate homotypic interactions. In the crystals, several charge-based intermolecular interactions between the N-terminal and C-terminal moieties of the ICAM-5 molecules were observed, which defined an interacting surface in the D1-D4 fragment. One of the crystal lattices has a molecular assembly that could represent the homophilic ICAM-5 cell adhesion complex in neurons.


  • Organizational Affiliation

    Centro Nacional de Biotecnología (CNB-CSIC), Campus Universidad Autónoma de Madrid, Darwin 3,, 28049 Madrid, Spain.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Intercellular adhesion molecule 5
A, B
378Homo sapiensMutation(s): 0
Gene Names: ICAM5TLCNTLN
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UMF0 (Homo sapiens)
Go to UniProtKB:  Q9UMF0
PHAROS:  Q9UMF0
GTEx:  ENSG00000105376
Glycosylation
Glycosylation Sites: 8Go to GlyGen: Q9UMF0-1
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
C, D, G, H, I
C, D, G, H, I, J, L
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
E, F, K
3N-Glycosylation
Glycosylation Resources
GlyTouCan:  G15407YE
GlyCosmos:  G15407YE
GlyGen:  G15407YE
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.70 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.230
  • R-Value Observed: 0.233
  • Space Group: P 43 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 96.07α = 90
b = 96.07β = 90
c = 321.92γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
PHASERphasing
PHENIXrefinement
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-07-16
    Type: Initial release
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2024-10-30
    Changes: Data collection, Database references, Structure summary
