4NDI | pdb_00004ndi

Human Aprataxin (Aptx) AOA1 variant K197Q bound to RNA-DNA, AMP, and Zn - product complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.182 (Depositor), 0.184 (DCC)
  • R-Value Work:
    0.154 (Depositor), 0.156 (DCC)
  • R-Value Observed:
    0.156 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 4NDI

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Aprataxin resolves adenylated RNA-DNA junctions to maintain genome integrity.

Tumbale, P.Williams, J.S.Schellenberg, M.J.Kunkel, T.A.Williams, R.S.

(2013) Nature 506: 111-115

  • DOI: https://doi.org/10.1038/nature12824
  • Primary Citation Related Structures:
    4NDF, 4NDG, 4NDH, 4NDI

  • PubMed Abstract:

    Faithful maintenance and propagation of eukaryotic genomes is ensured by three-step DNA ligation reactions used by ATP-dependent DNA ligases. Paradoxically, when DNA ligases encounter nicked DNA structures with abnormal DNA termini, DNA ligase catalytic activity can generate and/or exacerbate DNA damage through abortive ligation that produces chemically adducted, toxic 5'-adenylated (5'-AMP) DNA lesions. Aprataxin (APTX) reverses DNA adenylation but the context for deadenylation repair is unclear. Here we examine the importance of APTX to RNase-H2-dependent excision repair (RER) of a lesion that is very frequently introduced into DNA, a ribonucleotide. We show that ligases generate adenylated 5' ends containing a ribose characteristic of RNase H2 incision. APTX efficiently repairs adenylated RNA-DNA, and acting in an RNA-DNA damage response (RDDR), promotes cellular survival and prevents S-phase checkpoint activation in budding yeast undergoing RER. Structure-function studies of human APTX-RNA-DNA-AMP-Zn complexes define a mechanism for detecting and reversing adenylation at RNA-DNA junctions. This involves A-form RNA binding, proper protein folding and conformational changes, all of which are affected by heritable APTX mutations in ataxia with oculomotor apraxia 1. Together, these results indicate that accumulation of adenylated RNA-DNA may contribute to neurological disease.


  • Organizational Affiliation
    • 1] Laboratory of Structural Biology, National Institute of Environmental Health Sciences, NIH, DHHS, Research Triangle Park, North Carolina 27709, USA [2].

Macromolecule Content

  • Total Structure Weight: 55.9 kDa
  • Atom Count: 4,694
  • Modeled Residue Count: 400
  • Deposited Residue Count: 404
  • Unique protein chains: 1
  • Unique nucleic acid chains: 1
  • Unique hybrid chains: 1

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Aprataxin
A, B
182Homo sapiensMutation(s): 1
Gene Names: APTXAXA1
EC: 3.6.1.72 (UniProt), 3.6.1.71 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q7Z2E3 (Homo sapiens)
Explore Q7Z2E3
Go to UniProtKB:  Q7Z2E3
PHAROS:  Q7Z2E3
GTEx:  ENSG00000137074
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Z2E3
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 2
MoleculeChains LengthOrganismImage
5'-R(P*G)-D(P*TP*TP*AP*TP*GP*AP*TP*TP*C)-3'C [auth D],
E [auth G]
10N/A
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
5'-D(*GP*AP*AP*TP*CP*AP*TP*AP*AP*C)-3'D [auth E],
F [auth H]
10N/A
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
AMP

Query on AMP



Download:Ideal Coordinates CCD File
G [auth A],
L [auth B]
ADENOSINE MONOPHOSPHATE
C10 H14 N5 O7 P
UDMBCSSLTHHNCD-KQYNXXCUSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
K [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
BME

Query on BME



Download:Ideal Coordinates CCD File
J [auth A],
N [auth B]
BETA-MERCAPTOETHANOL
C2 H6 O S
DGVVWUTYPXICAM-UHFFFAOYSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
H [auth A],
M [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
K

Query on K



Download:Ideal Coordinates CCD File
O [auth D],
P [auth G]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
I [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.182 (Depositor), 0.184 (DCC)
  • R-Value Work:  0.154 (Depositor), 0.156 (DCC)
  • R-Value Observed: 0.156 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.468α = 90
b = 115.491β = 90
c = 116.173γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
SERGUIdata collection
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-12-18
    Type: Initial release
  • Version 1.1: 2014-01-15
    Changes: Database references
  • Version 1.2: 2014-02-05
    Changes: Database references
  • Version 1.3: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
