4KW4

Crystal Structure of Green Fluorescent Protein

PDB DOI: https://doi.org/10.2210/pdb4KW4/pdb

Classification: FLUORESCENT PROTEIN
Organism(s): Aequorea victoria
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2013-05-23 Released: 2014-04-09
Deposition Author(s): Barnard, T.J., Yu, X., Noinaj, N., Taraska, J.W.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.204
R-Value Work: 0.170
R-Value Observed: 0.172

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of Green Fluorescent Protein

Barnard, T.J., Yu, X., Noinaj, N., Taraska, J.W.

To be published.

Macromolecule Content

Total Structure Weight: 27.23 kDa
Atom Count: 2,175
Modelled Residue Count: 228
Deposited Residue Count: 239
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Green fluorescent protein	A	239	Aequorea victoria	Mutation(s): 5 Gene Names: GFP
UniProt
Find proteins for P42212 (Aequorea victoria) Explore P42212 Go to UniProtKB: P42212
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P42212
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CRO Query on CRO	A	L-PEPTIDE LINKING	C₁₅ H₁₇ N₃ O₅		THR, TYR, GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.75 Å
R-Value Free: 0.204
R-Value Work: 0.170
R-Value Observed: 0.172
Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.904	α = 90
b = 72.904	β = 90
c = 113.973	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction
SERGUI	data collection

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2014-04-09

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-04-09
Type: Initial release
Version 1.1: 2022-12-21
Changes: Database references, Derived calculations
